Dual Band 1.73Gbps Wireless For Intel AC 9560 9560D2W NGFF Key E Wifi Card 9560AC 802.11ac BT 5.0 Laptop for Windows 10

Transmission Rate:1.73Gbps
Certification:CE
Origin:CN(Origin)
Kind:Internal
Type:wireless
Application:Desktop
Wireless Protocol:802.11n
Adapter Socket:Other
Interface Type:Other
Wi-Fi Supported Frequency:2.4G & 5G
Transmission Speed:1200 Mbps
Package:Yes
Applicable Network Type:Gigabit Ethernet
Model Number:intel 9560D2W

Wireless-AC 9560
The  Wireless-AC 9560 adapter is a CRF(companion RF module)supporting the integrated wireless 802.11ac solutions from Intel.The solution provides Bluetooth 5 and 2x2 802.11ac Wi-Fi including wave 2 features such as 160MHz channels.These features deliver a significant increase in user speeds in dense deployments,supporting fast downloads and long life compared to legacy 802.11ac devices.Combined with Intel Core processors and exceptional wireless innovations,the Intel Wireless-AC 9560 can provide Gigabit wireless speed4 and dramatically improve your connected experience at home,work,or on the go.
It currently only support certain processors:
8th Gen Intel® Core processors
Intel® Pentium® Silver processors based on Gemini Lake
Celeron® processors based on Gemini Lake
Note:
Even though you can insert these CRF to a standard M.2 Key E socket, they are only compatible with a system designed with the CNVi. Contact your system or motherboard manufacturer to verify compatibility.
Description:
Model: Intel 9560D2W
Dual band:2.4Ghz / 5Ghz(160Mhz)
Max speed:Speed up to 1730Mbps (The router must on 160Mhz)
Bluetooth Version:BT5.0
IEEE WLAN Standard:IEEE 802.11a/b/g/n/ac
MU-MIMO:Supported
Antenna diversity:Supported
Radio ON/OFF control:Supported
Connector Interface:M.2:CNVio
Operating Temperature(Adapter Shield):0 to 80 (Celsius)
Supported Operating Systems:
Only work with Microsoft Windows 10
Note: Not support Windows 7/8/8.1
