EPON ONU XPON 1 port gPON WIFI 1GE+WIFI ONT ONU Manufacturer X

Origin:Mainland China
Compatible:Huawei
Fiber Type:Single Mode
Connector Type:SC/APC

Fiber Optical Networking Unit with wireless function
1GE WiFi XPON ONU fully meet the ITU-T technical standards and have good compatibility with third party manufacturers OLT. 1GE WiFi EPON ONU  can integrate with 802.11 b/g/n technical standards wireless function, It has built-in high gain directional antenna, the wireless transmission rate up to 300Mbps.
1GE WiFi EPON ONU is one of the EPON optical network unit design to meet the requirement of the broadband access network. It apply in FTTH/FTTO to provide the data service based on the EPON network.
EPON is the latest generations of access network technology. IEEE802.3ah is the standard protocol of. EPON networks provides the reliability and performance expected for business services and provides an attractive way to deliver residential services. EPON enables Fiber To The Home (FTTH) deployments economically resulting to accelerated growth worldwide.
1GE WiFi EPON ONU HSGQ-E100W have a high reliability and provide quality of service guarantee,easy management, flexible expansion and networking. It's fully meet the IEEE802.3ah technical standards and have good compatibility with third party manufacturers OLT.
1GE WiFi EPON ONU can integration wireless function with meet 802.11 b/g/n technical standards, It has built-in high gain
directional antenna, the wireless transmission rate up to 300Mbps. It has the characteristics of strong penetrating power and wide coverage. It can provide users with more efficient data transmission security.
Product Description
Item
Parameter
PON Interface
1 XPON optical interface
Downstream Data Rate:1.244Gbps
Upstream Data Rate:1.244Gbps
SC/PC single mode fiber
28dB Link loss and 20KM distance with 1:64
User Ethernet
Interface
1*10/100/1000M auto-negotiation
Full/half duplex mode
RJ45 connector
Auto MDI/MDI-X
100m distance
Power Interface
12V DC Power supply
PON
Optical
Parameter
Wavelength: Tx 1310nm, Rx1490nm
Tx Optical Power: 0~5dBm
Rx Sensitivity: -28dBm
Saturation Optical Power: -8dBm
Connector Type: SC
Optical Fiber: 9/125m single-mode fiber
Data Transmission
Parameter
PON Throughput: Downstream 1.244Gbit/s s; Upstream 1.244Gbit/s
Ethernet: 100Mbps or 1000Mbps
Packet Loss Ratio:
Business
Capability
Layer 3 wire speed switching
Support VLAN TAG/UNTAG,VLAN conversion
Support Port-based speed limitation
Support Priority classification
Support storm control of broadcast
Support loop detection
Network
Management
Support IEEE802.3 QAM, ONU can be remotely managed by OLT
Support Remote management through SNMP and Telnet
Local management
Management
Function
Status monitor, Configuration management, Alarm management,
Log management
Shell
Plastic casing
Power
Physical
Specifications
Item Dimension:135mm(L) x90mm(W) x 30mm (H)
Item weight:0.2kg
Environmental
Specifications
Operating temperature: 0 to 50ºC
Stora
