KIOXIA CD9P-R Series KCD9XPJE7T68 7,680 GB E3.S PCIe 5.0 NVMe 2.0 Data Center NVMe Read Intensive SSD KCD9XPJE7T68
- KIOXIA CD9P-R Series is a read intensive data center NVMe SSD that is optimized to support a broad range of scale-out and cloud applications. Built on PCIe® 5.0 and NVMe 2.0 technology, the CD9P-R Series SSDs deliver consistent performance up to 2,600K IOPS (random read) and 450K IOPS (random write).
- PCIe® 5.0, NVMe 2.0 specification compliant
- Open Compute Project Datacenter NVMe SSD specification v2.5 support (not all requirements)
- Form factor: E3.S, 7.5 mm thickness
- Proprietary KIOXIA architecture: controller, firmware and BiCS FLASH 3D TLC flash memory generation 5 and generation 8
- Single-port design optimized for data center class workloads
- Consistent performance and reliability for demanding 24x7 environments
- Designed for high-density storage deployments
- Power Loss Protection (PLP) and End-to-End Data Protection
- Security: SIE
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
- Capacity: 7,680 GB
- Basic Specifications:
- Form Factor: E3.S
- lnterface: PCIe® 5.0, NVMe 2.0
- Maximum Interface Speed: 128 GT/s (PCIe® Gen5 x4)
- Flash Memory Type: BiCS FLASH TLC
- Performance (Up to):
- Sustained 128 KiB Sequential Read: 14,800 MB/s
- Sustained 128 KiB Sequential Write: 7,000 MB/s
- Sustained 4 KiB Random Read: 2,600K IOPS
- Sustained 4 KiB Random Write: 450K IOPS
- Power Requirements:
- Supply Voltage: 12 V ± 10 %, 3.3 V ± 15 %
- Power Consumption (Active): 23 W typ.
- Power Consumption (Ready): 5 W typ.
- Reliability:
- MTTF:
- 2,500,000 hours @ 0 °C to 50 °C
- 2,000,000 hours @ 0 °C to 55 °C
- DWPD: 1
- Dimensions:
- Thickness: 7.5 mm +0.2 / -0.5 mm
- Width: 76 mm ± 0.25 mm
- Length: 112.75 mm ± 0.4 mm
- Weight: 110 g Max
- Environmental:
- Temperature (Operating): 0 °C to 75 °C
- Temperature (Non-operating): -40 °C to 85 °C
- Humidity (Operating): 5 % to 95 % R.H.
- Vibration (Operating): 21.27 m/s^2 {2.17 Grms} (5 to 800 Hz)
- Shock (Operating): 9.8 km/s^2 {1,000 G} (0.5 ms)
