Crestron DMF-CI-8 DigitalMedia 8 Slot Card Chassis for DM-NVX-C & DMCF

Crestron DMF-CI-8 DigitalMedia 8 Slot Card Chassis for DM-NVX-C & DMCF

Brand:  Crestron

Model:  DMF-CI-8

Product Type:  Card Chassis

USB Host:  For loading of firmware via a USB mass storage device

USB Device:  Computer console for setup

RS-232:  Computer console for setup

Card Slot ID 1 – 8:  Card slots; Each slot accepts DM-NVX-C series encoder/decoder card or DMCF series transmitter or receiver card

G:  6-32 screw;Chassis ground lug

100-240V~4.3-1.8A 50/60Hz:  IEC 60320 C14 main power inlet; Mates with removable power cord, included

Console, Serial (front):  8-pin RJ45 female; RS-232 computer console port

Console, USB (front):  USB Type-B female; USB computer console port

USB (front):  USB Type A female;Supports USB mass storage devices for firmware update

PWR:  Bi-color green/amber LED, indicates operating power supplied from AC line, turns amber while booting and green when operating

Status:  Bi-color green/red LED, indicates a normal (green) or critical error (red) condition

Display:  2 inch (52 mm) diagonal, 220 x 176 pixels, 16-bit TFT active matrix color LCD, displays IP address settings for each installed card

Nav Pad:  5-way navigation pad for menu navigation and adjustment of settings

Home:  Pushbutton, enters or returns to the home menu

Back:  Pushbutton, steps menu back one level

Card Slot Status, TX 1 – 8:  Green LEDs, each indicates the corresponding card is in transmitter mode

Card Slot Status, RX 1 – 8:  Green LEDs, each indicates the corresponding card is in receiver mode

Card Slot Status, OL 1 – 8:  Green LEDs, each indicates the corresponding card is online

Main Power:  4.3-1.8 Amps @ 100-240 Volts AC, 50/60 Hz

Power Consumption:  350 Watts fully loaded
