    MEAN WELL LRS-200-5 200W 5V 40 Amp Single Output Switchable Power Supply

    • Primary output voltage (vdc): 5
    • Output current (a): 40
    • Maximum output power (w): 200
    • Family: lrs-200
    • Input voltage (vac): 90 to 132, 180 to 264
    +
    +
    Overview
    Specs
    Reviews
    avatar

    Any questions? Our AI beta will help you find out quickly.

    200W 5V 40A Single Output Switchable Power Supply 5 Volts 40 Amps Features AC input range selectable by a switch Withstand 300 VAC surge input for 5 seconds No load power consumption 1U low profile High operating temperature, up to 70°C
    Protections: Short circuit / Overload / Over voltage / Over temperature Cooling by free air convection Compliance to UL 60950-1 Withstand 5G vibration test High efficiency, long life and high reliability LED indicator for power on 100% full load burn-in test 3 year warranty Applications Industrial automation machinery Industrial control system Mechanical and electrical equipment Electronic instruments, equipment or apparatus Related Products LRS-200- 3.3 ( 3.3V 40A, 132W)
    Jameco P/N: 2219698 LRS-200- 4.2 ( 4.2V 40A, 168W)
    Jameco P/N: 2219701 LRS-200-12 (12V 17A, 204W)
    Jameco P/N: 2219727 LRS-200-15 (15V 14A, 210W)
    Jameco P/N: 2219735 LRS-200-24 (24V 8.8A, 211W)
    Jameco P/N: 2219743 LRS-200-36 (36V 5.9A, 212W)
    Jameco P/N: 2219751 LRS-200-48 (48V 4.4A, 211W)
    Jameco P/N: 2219760 LRS-150 Series (150 Watt, Enclosed Switchable Single Output Power Supply) LRS-150F Series (150 Watt, Full Range Input Enclosed Switching Power Supply) LRS-350 Series (350 Watt, Enclosed Switchable Single Output Power Supply) Detailed

    Specifications

    : Primary
    Output Voltage (VDC): 5
    Output Current (A): 40 Maximum
    Output Power (W): 200
    Family: LRS-200
    Input Voltage (VAC): 90 to 132, 180 to 264
    Input Frequency: 47 to 63
    Maximum Input Current (A): 4 Output
    Connector Type: Screw Terminal Block Number of
    Outputs: 1
    Product Type: AC to DC
    Power Supply Efficiency (%): 87 (more. ).
