ZZEW C4P MATX PC Case Compact Desktop Micro ATX Computer Case Fits ATX Power Supply &360 Water Cooling
- ZZEW C4P MATX CASE: Full aluminum CNC case with frame thickness 2.0mm, capacity 23.9L, size 423*196*289(mm) /16.65*7.72*11.38(inch) and net weight 3.0(kg) /6.61(lb)
- Power Supply: Standard ATX (140*150*86mm)
- Motherboard: MATX(245*245mm) /ITX(170*170mm) ( I/O frame crossing 6mm)
- Hard Drives: 3.5" HDD*1 or 2.5" SSD*2
- Graphics Card: Support 400*169*78mm(without I/O) size high-performance large GPU, compatible with 99% of GPU on the market
- Water Cooling: High-spec 360 water cooling, with a maximum length of 397 mm. The top supports 360mm water cooling*1 or 240/120mm water cooling, can also support high-specification GPU. The maximum height of the memory is limited to 44mm
- Air Cooling: A 166mm High tower cooler + 7*12025 fans for assistance
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Case Parameters: Case
size: 423*196*289mmCase
Capacity: 23.9LM
aterial: AL-MG high strength magnesium aluminum alloyCase
Color: Anodized silverFrame
Thickness: 3.0
mmOther components thickness: 1.5 mmSide
Aluminum panel thickness: 2.0 mmSide Explosion-proof tempered
glass panel thickness: 3.0
mmNet weight: 3.0KGG
ross weight: 4.2KG (including package)
Package Size: 505*270*370mmHardware Supporting
Motherboard: MATX (245*245mm) /ITX (170*170mm) ( I/O frame crossing 6mm)Power
Supply: Standard ATX (140*150*86mm) Option 1When the PSU is installed in position 1, the top supports 240/360 water-cooled or 120 fan *1, and the GPU is limited to a length of 400mm(If GPU air outlet is in the direction of the backplane, PSU air inlet face upwards recommended )Option 2360 water cooling or 120 fan *3 at the topCan support backing wire and fixed PSU need to be supported by a bracketGraphics
Card:
Size: 400*169*78mm(without I/O)(supports high-performance large GPU, compatible with 99% of GPU on the market) *GPU installation area size 400*169*78mm. When a 25mm fan installed on the bottom, the thickness of the GPU behind the fan is approximately 60mmFan:
Up:
12025*2-3Bottom: 12025*0-3Rear
Window: 12025*1CPU Radiation (Air
Cooling): A 166mm High tower cooler + 7*12025 fans for assistanceCPU Radiation (Water
Cooling): High-spec 360 water cooling, with a maximum length of 397 mmThe top supports 360mm water cooling*1 or 240/120mm water cooling, can also support high-specification GPU. The maximum height of the memory is limited to 44mmHardware: 3.5" HDD*1 or 2.5" SSD*2 (Flat installation) If GPU length>305mm and thickness>60mm, 3.5" HDD is incompatible, but 1-5* 2.5" SSD
If GPU length305mm and thickness60mm, bottom supports horizontal installation of 1-3* 3.5" HDD, or 1-5* 2.5 " SSD (Vertical installation) If GPU length <385mm, 1-3*3.5" HDD can be vertical installed, or 1-8* 2.5" SSD (PSU installed by option 1)For every 30mm reduction in GPU length, an additional 3.5 HDD can be added by vertically installed, up to a maximum of
3. For every 15mm reduction in GPU length, an additional 2.5 SSD can be added vertically installed, up to a maximum of 8Front interface: Aluminum Power Button * 110G/Type-C * 15G USB 3.0 * 13.5 audio mic 2-in-1 interface*1Package
Including: C4P Case *1 Accessory Box * 1 9cm fan dust net * 1
size: 423*196*289mmCase
Capacity: 23.9LM
aterial: AL-MG high strength magnesium aluminum alloyCase
Color: Anodized silverFrame
Thickness: 3.0
mmOther components thickness: 1.5 mmSide
Aluminum panel thickness: 2.0 mmSide Explosion-proof tempered
glass panel thickness: 3.0
mmNet weight: 3.0KGG
ross weight: 4.2KG (including package)
Package Size: 505*270*370mmHardware Supporting
Specifications
:Motherboard: MATX (245*245mm) /ITX (170*170mm) ( I/O frame crossing 6mm)Power
Supply: Standard ATX (140*150*86mm) Option 1When the PSU is installed in position 1, the top supports 240/360 water-cooled or 120 fan *1, and the GPU is limited to a length of 400mm(If GPU air outlet is in the direction of the backplane, PSU air inlet face upwards recommended )Option 2360 water cooling or 120 fan *3 at the topCan support backing wire and fixed PSU need to be supported by a bracketGraphics
Card:
Size: 400*169*78mm(without I/O)(supports high-performance large GPU, compatible with 99% of GPU on the market) *GPU installation area size 400*169*78mm. When a 25mm fan installed on the bottom, the thickness of the GPU behind the fan is approximately 60mmFan:
Up:
12025*2-3Bottom: 12025*0-3Rear
Window: 12025*1CPU Radiation (Air
Cooling): A 166mm High tower cooler + 7*12025 fans for assistanceCPU Radiation (Water
Cooling): High-spec 360 water cooling, with a maximum length of 397 mmThe top supports 360mm water cooling*1 or 240/120mm water cooling, can also support high-specification GPU. The maximum height of the memory is limited to 44mmHardware: 3.5" HDD*1 or 2.5" SSD*2 (Flat installation) If GPU length>305mm and thickness>60mm, 3.5" HDD is incompatible, but 1-5* 2.5" SSD
If GPU length305mm and thickness60mm, bottom supports horizontal installation of 1-3* 3.5" HDD, or 1-5* 2.5 " SSD (Vertical installation) If GPU length <385mm, 1-3*3.5" HDD can be vertical installed, or 1-8* 2.5" SSD (PSU installed by option 1)For every 30mm reduction in GPU length, an additional 3.5 HDD can be added by vertically installed, up to a maximum of
3. For every 15mm reduction in GPU length, an additional 2.5 SSD can be added vertically installed, up to a maximum of 8Front interface: Aluminum Power Button * 110G/Type-C * 15G USB 3.0 * 13.5 audio mic 2-in-1 interface*1Package
Including: C4P Case *1 Accessory Box * 1 9cm fan dust net * 1
