PCI-E Serial Port Card, PCIe to COM Port RS232 Interface Adapter, Industrial Expansion Card, AX99100, New Model 1-Port Parallel LPT
- PCI Express
- Single-channel (X1) PCI Express endpoint, with a controller integrated with PHY
- Complies with PCI Express card specifications, PCI Express 2.0 Gen 1
- Complies with PCI Power Management 1.2
- Supports traditional and MSI interrupts, ASPM power management
- RS-232 serial port interface
- Dual or Quad UART
- Supports multiple protocols such as RS-232 / RS-422 / RS-485
- Each port supports bidirectional speed up to 25 Mbps
- Full serial modem control
- Supports hardware and software flow control
- Supports 5, 6, 7, 8 and 9-bit serial formats
- Supports even, odd, none, space and mark parity checks
- Supports custom baud rate through internal PLL or external clock
- Supports on-chip 256-byte deep FIFO for each serial port's transmission and reception paths
- Supports remote wake-up and power supply
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
AX99100 is a single-chip solution that can fully integrate the PCIe 2.0 Gen 1 endpoint controller and SerDes with various peripheral devices.
Such as two/four high-speed serial ports, one parallel port, an I2C master device, high-speed SPI, local bus (ISA-like) and GPIO.
It consists of four main configurations, such as 2S (PCIe to Dual Serial), 2S + 1P (PCIe to Dual Serial and Single Parallel).
2S + SPI (PCIe to dual serial and SPI) and LB (PCIe to local bus/ISA) - Like) are suitable for various types of applications.
AX99100 is packaged in a 68-pin QFN format and complies with the RoHS standard. It supports a commercial operating temperature range of 0 to 70°C and an industrial temperature range.
The range is from -40°C to 85°C.
Management functions
Serial port transceiver shutdown support
Support for slow IrDA mode (115200 bps)
On all serial ports
Support for multi-point applications in 9-bit mode
Support for DMA burst transmission
Compatible devices
Serial-connected devices, serial network/monitoring devices, data acquisition systems, POS terminals and industrial PCs, serial I/O of add-on cards
USB and I/O expansion for embedded systems
Operating System
Windows 98SE/Me/NT4.0/2000/XP/Server 2003/Vista/Win 7/Win 8/Win 10, Linux, DOS
