Waterproof Transfomer Converts 120V-277V AC to 12/24 Volts DC - 16 amps Straight Blade Wall Plug(-12

Larson Electronics DCP-16-DP waterproof power supply converts commonly used 120 - 240VAC electrical current to low voltage. This 120 watt converter comes with a straight blade plug on the input lead and a two pin Deutsch connector on the output lead allowing users to simply plug the unit into a typical wall outlet. This unit is IP67 rated waterproof and suitable for indoor or outdoor applications. Integrally designed protection includes overload short circuit over temperature and over voltage safeguards to prevent overheating and unit damage in case of faults or overly heavy current draw. This unit will limit current when an over current condition is encountered and recovers when the condition is removed.

This unit will enter hiccup mode under short circuit conditions and recover when the fault is removed. The unit will also shut down when an over temperature condition occurs and recovers automatically when the temperature returns to normal levels. This power converter has a -30 / +60C operating temperature range and is UL UL1012 and UL60950-1 compliant as well as compliant with worldwide safety regulations for lighting. This unit has a 90% conversion efficiency and is suitable for use with moving LED signs and similar LED equipment. These units also feature Power Factor Correction adjustable output current range from 8 ~ 16A either through the output cable or internal potential meter and have an input frequency range of 47 ~ 63Hz.

In order to obtain the best performance and the longest operational life from these units it is recommended that you do not exceed 75% of the units output amperage.
