315MHz AC220V Wireless Remote Control Switch 6-IN-1 Remote Control One Channel 1000m Long Distance

Features:

The receiving board of the remote controller is suitable for electric control circuits such as anti-theft alarm, remote control of electric doors and windows, signal control, industrial control, lifting equipment, etc. Relay contacts of remote control switch module output independently, which is very suitable for direct control of all kinds of loads. The product adopts fixed code wireless coding technology, without directionality, and switches do not interfere with each other.

The receiving board can withstand up to 10A current per circuit and drive AC load directly. Each relay has a set of normally open (normally closed) contacts.

Specification:

Product model: RD1CH

Operating Voltage: 220V

Working frequency: 315MHZ

Contact capacity: <10A/250VAC; 10A/30VDC

Receiving sensitivity: >-105dB

Remote control distance: 1000 meters

(No interference in open space) This distance is the theoretical distance without interference, and it will be reduced according to different environmental disturbances and partition walls during use. Generally it is about 10%-50% of the nominal distance.

Number of control channel: 1

Remote control battery: 12V23A

Operation method:

Short press operation

(press and leave

less than 5 seconds) button can be switched to jog, interlock and self-locking working status in turn, and the current working status is indicated by LED indicator:

Short press the operation button once, the LED flashes once, this is the jog mode

Press the operation button again shortly, the LED flashes twice, this is the interlocking mode

Press the operation button again, the LED flashes three times, this is the self-locking mode

Short press again to repeat the a operation.
