BIOSTAR TH67+ LGA 1155 Intel H67 HDMI USB 3.0 Micro ATX Intel Motherboard
- Intel H67
- Core i7 / i5 / i3 (LGA1155)
- DDR3 1333/1066
Specs
Reviews (96)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Biostar TH67+
| Brand | BIOSTAR |
|---|---|
| Model | TH67+ |
| CPU Socket Type | LGA 1155 |
|---|---|
| CPU Type | Core i7 / i5 / i3 (LGA1155) |
| Chipset | Intel H67 |
|---|
| Onboard Video Chipset | Supported only by CPU with integrated graphic |
|---|
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR3 1333/1066 |
| Maximum Memory Supported | 32GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 2 (x16, x4) |
|---|---|
| PCI Express x1 | 1 x PCI Express x1 |
| PCI Slots | 1 x PCI Slot |
| Serial ATA (SATA) | 2 x SATA 6Gb/s |
|---|---|
| SATA RAID | 0/1/5/10 |
| Audio Chipset | Realtek ALC892 |
|---|---|
| Audio Channels | 6 Channels |
| LAN Chipset | Realtek 8111E |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 1 x HDMI / 1 x PS/2 Keyboard/Mouse Combo / 2 x USB 2.0/1.1 / 2 x USB 3.0 |
|---|---|
| PS/2 | 1 x PS/2 Keyboard |
| Video Ports | D-Sub + DVI |
| HDMI | 1 x HDMI |
| USB 3.0 | 2 x USB 3.0 |
| USB 1.1/2.0 | 2 x USB 2.0 |
| Audio Ports | 3 Ports |
| Onboard USB | 6 x USB 2.0 |
|---|
| Form Factor | Micro ATX |
|---|---|
| Dimensions (W x L) | 9.6" x 9.06" |
| Power Pin | 24 Pin |
| Features | Supports the Intel 2nd generation Core i7 and Core i5 processors in the 1155 package Intel H67 single chip architecture Support 4-DIMM DDR3-1333/1066 up to 16G maximum capacity Support ATI CrossfireX Technology Support SATA 6Gb/s 2X speed than current SATA 3G Support USB 3.0 100% X.D.C solid capacitor BIOSTAR G.P.U (Green Power Utility) Technology for Energy Saving BIOSTAR Toverclocker utility |
|---|
| Date First Available | January 08, 2011 |
|---|
