ASRock H170M-ITX/DL LGA 1151 Intel H170 HDMI SATA 6Gb/s USB 3.1 Mini ITX Intel Motherboard

Sold and Shipped by Newegg

Purchases from these Sellers are generally covered under our Newegg Marketplace Guarantee.
Marketplace Seller
  • Intel H170
  • Supports 7th and 6th Generation Intel Core i7/i5/i3/ Pentium/Celeron Processors (Socket 1151)
  • DDR4 2133

  • Overview
  • Specifications
  • Warranty & Returns
  • Reviews
general information

The ASRock H170M-ITX/DL is built in Mini ITX form factor with the finest components and provides the industry-leading features, offering you more than enough for an exceptional experience in every aspect.

  • ASRock Super Alloy
  • Supports 6th Generation Intel Core Processors (Socket 1151)
  • Digi Power, 6 Power Phase design
  • Supports Dual Channel DDR4 2133
  • 1 PCIe 3.0 x16, 1 Vertical Half-size Mini-PCIe
  • Graphics Output Options: DVI-D, HDMI
  • 7.1 CH HD Audio (Realtek ALC892 Audio Codec), ELNA Audio Caps
  • Dual LAN : Intel I219V + Realtek RTL8111H
  • 4 SATA3, 1 mSATA
  • 8 USB 3.0 (2 Front, 6 Rear)
  • Supports Full Spike Protection, ASRock Live Update & APP Shop
general information

Premium 45A Power Choke

Compared to traditional chokes, ASRock’s premium 45A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the motherboard.

Dual-Stack MOSFET for CPU Power

Dual-Stack MOSFET (DSM) is another innovative MOSFET’s design by ASRock. The silicon die area is increased by stacking two dies into one MOSFET. The larger the die area, the lower Rds(on). Compared to traditional discrete MOSFET, DSM with larger die area provides extreme lower Rds(on) 1.2 mO, so the power supply for the CPU Vcore is more efficient.

viewing viewing

High Density Glass Fabric PCB

What you’ve never understood about your computer is that it is scared to death of water, H2O, humidity or whatever you’d like to name it. And even though you do not see the water, actually there may be lots of excessive moist in the air killing your motherboard silently and slowly. No, your motherboard doesn’t melt when in contact with water like the wicked witch of the west, but it dies of short circuit. Luckily, ASRock has a new High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity.

viewing viewing

DDR4 Non-Z OC

Overclocking DDR4 memory modules is no longer limited to Z170 models. With ASRock’s DDR4, Non-Z OC users may overclock the memory of H170/Q170/B150/H110/C232 models using certain memory sticks, such as Kingston or Samsung memory DIMMs. The enhanced CAS latency brings up to 5% performance boost.

general information

6 Power Phase Design

The power phase design offers smooth power delivery to the CPU, unmatched overclocking capabilities, lower temperature for advanced gamers, and reinforced system stability for taking on all sorts of arduous computing tasks.

general information

UEFI EZ Mode

EZ mode is a dashboard which contains multiple readings of the system’s current status. You can check the most crucial information of your system, such as CPU speed, DRAM frequency, SATA information, fan speed, etc.

general information

general information

Dual Gigabit LAN

Users are able to connect two LAN cables to this motherboard's rear I /O.

general information

Solid Capacitor Design

ASRock applied solid capacitors on this motherboard. With these solid caps, this motherboard is allowed to perform more stably and ensure longer lifetime.

general information

ELNA Audio Caps

Who says high quality audio is only available on high-end motherboards? ASRock applied ELNA audio capacitors on mainstream and entry-level motherboards! Compared with traditional solid caps, the leakage current of ELNA audio caps is merely 3uA. This is the key to reduce noise level significantly and satisfy even the pickiest audiophiles.

general information

Digi Power

Unlike traditional motherboards that use analog power, this motherboard uses a next generation digital PWM (Pulse-Width Modulation) design, which provides CPU Vcore voltage more efficiently and smoothly, so that the stability and lifespan of the motherboard is greatly enhanced.

general information

Supports DDR4 2133

This motherboard supports the latest DDR4 memory modules and most extreme memory performance.

general information

Win 7 USB Patcher

Due to chipset limitation, when you want to install Windows 7 on this MB, you may need to use “Win 7 USB Patcher” to create a new ISO file.

general information

A-Tuning

A-Tuning is ASRock's multi-purpose software suite with a new interface, more new features and improved utilities.

general information

Live Update & APP Shop

ASRock Live Update & APP Shop is designed for your convenience. ASRock provides various apps and supports software for users to download. You can also easily optimize your system and keep your motherboard up to date with ASRock Live Update & APP Shop.

general information

Full Spike Protection

Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection includes various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes.

general information

ASRock Cloud

ASRock Cloud technology makes your mobile devices connect to your PC seamlessly and supports multi devices for accessing File Explorer cloud service simultaneously!

general information

USB Key

In a world where time is money, why waste precious time everyday typing usernames to log in to Windows? Why should we even bother memorizing those foot long passwords? Nobody has time for that! Just plug in the USB Key and let your computer log in to windows automatically!

general information

Restart to UEFI

Fast Boot is so fast that it is impossible for users to enter the UEFI setup utility during POST. Therefore, ASRock Restart to UEFI technology allows users to easily enter the UEFI setup utility automatically when turning on the PC next time. It is designed for those who constantly need to enter the UEFI setup utility.

general information

ASRock OMG (Online Management Guard)

Limit and control your children's time spent on the internet. ASRock OMG (Online Management Guard) technology allows you to establish an internet curfew or restrict internet access at specified times. Administrators are able to schedule the starting and ending hours of internet access granted to other users.

general information

UEFI Tech Service

Contact ASRock Tech Service by sending a support request from the UEFI setup utility if you are having trouble with your personal computer. Users may try to choose the category of the issue they have encountered, describe the problem in detail, and then attach an optional picture or log file for ASRock’s technical support team.

general information

Easy Driver Installer

For users that don’t have an optical disk drive to install the drivers from ASRock’s support CD, Easy Driver Installer is a handy tool in the UEFI that installs the LAN driver to your system via an USB storage device, then downloads and installs the other required drivers automatically through the internet. Completely no CD or optical disk drive required!

general information

ASRock XFast RAM

ASRock XFast RAM fully utilizes the memory space that cannot be used under Windows® 32-bit operating systems. It shortens the loading time of previously visited websites, making web surfing faster than ever. And it also boosts the speed of Adobe Photoshop 5 times faster. Another advantage of ASRock XFast RAM is that it reduces the frequency of accessing your SSDs or HDDs in order to extend their lifespan.

general information

ASRock XFast LAN

When Internet Explorer loads very slowly for no clear reason, it's usually due to inefficient management. ASRock is rolling out super-efficient web management in the motherboard industry. XFast LAN is a convenient tool that controls internet related applications easily and efficiently. Creating a perfect Internet environment, all you need is a smart manager. ASRock XFast LAN allows you to enjoy more speed, easier multitasking, enhanced multimedia experience, and more – all without weighing you down.

general information

HDMI-ready

This motherboard supports HDMI (High-Definition Multimedia Interface) which is an interface standard for transferring uncompressed video data and delivering multi-channel audio through a single cable. Both video and audio data signals transferred through the HDMI™ interface are digital without being converted into analog, therefore it delivers the richest pictures and the most realistic sounds.


Learn more about the ASRock H170M-ITX/DL

Warranty, Returns, And Additional Information
  • Warranty
  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 3 years
  • Read full details
  • Return Policies
    • Return for refund within: 30 days
    • Return for replacement within: 30 days
  • This item is covered by Newegg.com's Standard Return Policy.
Ownership: more than 1 year
Verified Owner
4/ 5
An updated review after a few years of use 4/13/2019 12:17:23 PM

Pros: Bought this board to use with a 6th gen CPU since I'm not interested in using Win10 at all. It has been a good stable board for me with the exception of the cons I've listed below.

Cons: I only have 2 issues with this board, one of which is Intel's fault and NOT ASRock's.
1) My first issue is the USB on this board. It is flakey as all heck! It will often glitch out on a given port if you plug a USB drive in and then take it out and then plug it back in to the same port. It won't recognize the drive again and you will need to switch to a diff port to make it work. This is an issue on both my board regardless of the OS I'm using. An add-on USB card is the solution for this for me but it wouldn't work for someone who wants to use an aftermarket GFX.
2) First off i want to say, thanks ASRock for using an Intel NIC instead of lowgrade Realtek. Having said that, the Intel NIC will often disconnect in windows. Win7 or Win10, it doesn't matter. This does not happen with Linux OS's tho. After a lot of work and trial and error I've found the cultprit is the Intel Pro-Set drivers. If you install them they put the adapter into low power mode which causes disconnects, even if you are using the NIC!. The fix for this is just to use Intel or MS basic drivers and disable all "power saving" options. Then the NIC works perfectly.

Overall Review: I did post this same cons list on the ASRock Z270M Pro4 LGA 1151 Intel Z270 board because it has the same issues as this board does. It is basically just a larger version of this board.

Did you find this review helpful?
Ownership: 1 month to 1 year
Verified Owner
1/ 5
Not a great motherboard 10/16/2017 2:00:51 PM

Pros: None. It never worked for me.

Cons: Always read the reviews before you purchase!
As many here note, this board will not work (POST) out of the box with the latest processors (Kaby Lake). Supposedly, ASRock will send a chip with the updated BIOS that will allow those processors to work. ***It took more than three weeks for them to send me a chip.*** Still no POST with my new i5-7600K Kaby Lake.

Also, the manual has no troubleshooting section. Because there is none! Ha! Not a single LED on board. No audio codes. Nada. There don't seem to be any POST codes, but that's not a problem because it doesn't POST!

Overall Review: Buyer beware.

Did you find this review helpful?
Manufacturer Response:
Dear Matthew,

We sincerely apologize for any inconvenience this may have caused you.
Please check if the BIOS chipset is properly installed (check and match the notch orientation).
If install correctly, please trouble shoot the mainboard whether the issue is resolved.
• Unplug the ATX power, remove all components from mainboard.
• Remove the mainboard from chassis, place it on mainboard’s box.
• Clear the CMOS.
• Reseat the CPU and heatsink fan.
• Test with single memory module.
• Test with onboard video.
• Connect the monitor (to onboard video).
• Plug the 24 + 4 pins ATX power.
• Connect the chassis power switch to mainboard.
• Turn on the power to check if its post.

If you have any technical support inquiry, please contact us at http://www.ASRock.com/Support/tsd.asp
We will assist you shortly.

Thank you

ASRock Support
Tech Support Email: http://www.ASRock.com/Support/tsd.asp
Ownership: 1 week to 1 month
Verified Owner
1/ 5
Not working 8/25/2017 7:48:03 PM

Pros: Nothing

Cons: ASRock declare this MB is supporting 6th & 7th gen of Intel CPU. They lie. This MB is sold with old BIOS and it doesn't support 7th generation. ASRock replied on reviews 'Sorry but you can contact us and we will send the BIOS for you!'. I have tried it. They replied and promised they will send the BIOS. They never send it - I didn't receive it in last 22 days and when I ask if it was sent they didn't respond anymore.
So - based on this experience - don't trust ASRock. I have whole PC and I cannot use it because ASRock lied. When I asked for help they lied again and I wait for almost one month for nothing. This is BAD.

0 out of 2 people found this review helpful. Did you?
Manufacturer Response:
Dear Jan,

We sincerely apologize for any inconvenience this may have caused you.
Wonder that you also call us for immediate assistance.
However, we will be more than happy to send the updated BIOS chip.
Please contact us at 909-590-8308 (business days/hours) or http://www.ASRock.com/Support/tsd.asp
We will assist you shortly.

Thank you

ASRock SUPPORT
Tech Support Email: http://www.ASRock.com/Support/tsd.asp
Ownership: 1 day to 1 week
Verified Owner
2/ 5
Check CPU/ BIOS compatible before ordering! 8/18/2017 6:07:19 AM

Pros: Looks like a nice motherboard for the price

Cons: Ordered Aug 2017 and board received had BIOS version 2.0. Bios Version 7.0 came out Nov 2016 and most recent CPUs require BIOS version 7.0. Without this version, board will not post with recent Intel Kaby Lake CPU's. I've already sent AS Rock a tech support request and will wait and see how this handled.

0 out of 2 people found this review helpful. Did you?
Manufacturer Response:
Dear Wade,

We sincerely apologize for any inconvenience this may have caused you.
Due to the mainboard had been released before Kabylake (7th Gen) processor, the BIOS update is required to support new processor.
However, we will be more than happy to send the updated BIOS chip.
Please contact us at 909-590-8308 (business days/hours) or http://www.ASRock.com/Support/tsd.asp
We will assist you shortly.

Thank you

ASRock SUPPORT
Tech Support Email: http://www.ASRock.com/Support/tsd.asp
Ownership: 1 month to 1 year
Verified Owner
3/ 5
Compatible with older OSs 7/24/2017 8:31:33 AM

Pros: Relatively inexpensive at $80
Dual gbe (Intel i219V and Realtek 8111)
The mini PCIe slot is msata capable (and not shared with the 4 SATA slots)
With BIOS update 7.00 will accept Kaby Lake processors.

Cons: Can't find server 2008 R2 drivers for the i219V ethernet. Had to use drivers for the i219e
The vertical orientation of the mini-PCIe / MSATA slot can make mounting an SSD a PITA.
Motherboard came with the 2.00 BIOS.

Overall Review: A decent Skylake chipset motherboard for the price. Purchased for a quick bare-metal windows server lab. If you want to use an msata drive in the vertical slot, you might want to consider a half-length model if your enclosure is height-limited.

Did you find this review helpful?
Manufacturer Response:
Dear Nam,

Thank you for purchase and review.
Mainboard does not provide Server or Linux OS drivers. However, they are based on chipset vendors.
Please visit link below for supported OS under OS section.
Specification link: http://www.asrock.com/mb/Intel/H170M-ITXDL/index.us.asp?cat=Specifications

If you have any technical or warranty inquiry, please contact us at http://www.ASRock.com/Support/tsd.asp
We will assist you shortly.

Thank you

ASRock SUPPORT
Tech Support Email: http://www.ASRock.com/Support/tsd.asp
Anonymous
Ownership: 1 week to 1 month
Verified Owner
1/ 5
DOA or not working with 7th generation (i3-7100), new chip from support didn't help 7/13/2017 7:54:03 AM

Pros: price
ITX

Cons: dead or not working with 7th generation (i3-7100)
slow support, get new chip in 10 days

0 out of 2 people found this review helpful. Did you?
Manufacturer Response:
Dear Valued ASRock Customer,

We sincerely apologize for any inconvenience this may have caused you.
Due to the mainboard had been released before Kabylake (7th Gen) processor, the BIOS update is required to support new processor.
However, we will be more than happy to send the updated BIOS chip.
If you have any technical support inquiry in the future, please contact us at 909-590-8308 (business days/hours) or http://www.ASRock.com/Support/tsd.asp
We will assist you shortly.

Thank you

ASRock SUPPORT
Tech Support Email: http://www.ASRock.com/Support/tsd.asp
Ownership: 1 month to 1 year
Verified Owner
4/ 5
Surprisingly nice for what it is! 6/18/2017 12:15:38 PM

Pros: Originally bought for the tons of USB 3.0 ports and Dual RJ-45 Ethernet, which is nice for system admins. It seems like there's been a lot stuffed in this model, but for a Mini-ITX, I can't complain for what it is. A worthy micro computing motherboard. The 20-Pin ATX Power connector also makes this system a little easier to pair with legacy cases and/or PSU's. BIOS/UEFI is very nice to use in comparison to some other interfaces.
Paired with a i3-6100 and a Desktop GPU and I love what it can do.

Cons: Mostly personal preference, but I wish there was at least one more Fan Header, and at least one more place for another M-Sata card, but the configuration is fine all-in-all for what it costs, which is a bit high. I also wish the audio chipset was a little more familiar to *nix operating systems. I use Linux primarily with this system, and Pulse Audio seems to have an issue in that it won't transmit audio to the front panel nor the rear connectors except for HDMI. This is problematic if I advertise to every other person how great Linux is if there are problems from the start. I'm sure this isn't the case with every Linux, but it seems to be for Ubuntu 14.04.

Overall Review: I'd have to say I'm overall happy with this product, but because I use Linux, I had to take off an egg. Not that it should affect Windows users, but Linux users might have issues.

Did you find this review helpful?
Ownership: 1 month to 1 year
Verified Owner
2/ 5
Been running for 4 months. 4/11/2017 5:51:02 PM

Pros: I'm writing this review while running my build on it.
It fit into my budget for the build I wanted.

Cons: Despite updating the bios, the motherboard won't reboot. It gets caught in a loop and has to be forcibly powered off and then on.

Overall Review: I've owned two ASRock motherboards, the first one was DOA and this one has problems. I don't think I'll be buying another ASRock product.
Just on Newegg to price a new motherboard because I'm tired of not being able to reboot my computer every time an update is installed.

Did you find this review helpful?
Manufacturer Response:
Dear Benjamin,

We sincerely apologize for any inconvenience this may have caused you.
Please try following steps whether the issue is resolved.
• Turn off the power, clear the CMOS.
• Test with single memory module, switching another memory stick if problem still persist.

If you have any technical support or warranty inquiry, please contact us at http://www.ASRock.com/Support/tsd.asp
We will assist you shortly.

Thank you

ASRock Support
Tech Support Email: http://www.ASRock.com/Support/tsd.asp
ICON Loading...
Selected Items
Are you an E-Blast Insider?

Subscribe Newegg e-Blast
PayPal
Shop without retyping payment details. Secure shopping made faster.
Check out with PayPal.

Condition Guidelines

The following guidelines apply to all product categories unless otherwise indicated within specific categories.

  • New : This means the product will ship as received by the manufacturer, sealed, with all advertised components, and with the manufacturer warranty.
  • Refurbished : This means the product was tested and repaired as required to meet the standards of the refurbisher, which may or may not be the original manufacturer. Any exceptions to the condition of the item outside the manufacturer’s information should be provided in the listing, up to and including warranty details.
  • Open Box : Newegg only guarantees your receipt of the Open Box product with the purchase of this item. Any accessories MAY OR MAY NOT be included. Newegg will NOT send you any missing accessories, even if it is required to use all of the item’s functions.Open Box items usually do not come with manufacturer or vendor warranty or technical support. However, warranty support may be available if an item was never registered by a previous owner. Please contact the manufacturer to check.
  • Used - Like New : This means that the product has been opened, possibly used but is in perfect condition with no signs of cosmetic or functional defect. Product may includes warranty, and accessories found with the original product. Product may or may not be in the original packaging. Returned items with minor packaging defects fall under this category.
  • Used - Very Good : This means that the product has been opened, may show slight signs of use and cosmetic blemish, and may be missing minor accessories, but remain in excellent condition. Product does not come with warranty unless stated otherwise in product description.
  • Used - Good : This means that the product has been used, may show clear signs of use and may be missing minor accessories, but remain in good condition. Product does not come with warranty unless stated otherwise in product description.
  • Used - Acceptable : This means that the product shows clear signs of use, cosmetic defect, and may be missing minor accessories and manual, but remain in working condition. Product does not come with warranty unless stated otherwise in product description. Functionality issues beyond signs of use should be disclosed in product description.
Price Available at Checkout
Why can’t we show you details of this product?

Some manufacturers place restrictions on how details of their products may be communicated.

If the Adobe Reader does not appear when you click on a link for a PDF file, you can download Adobe Reader from the Adobe web site.

Your Personal Data

Newegg’s website and online services use cookies and similar technology for a number of reasons: Some technologies allow the site to function. These functional cookies are required to use the site and complete purchases. Another set of technologies improve the browsing experience and personalize it. Here are all the details about Newegg’s Cookie and Privacy Policies. Please select and accept your settings before you continue. Thank you.

Your Personal Data

Newegg’s website and online services use cookies and similar technology for a number of reasons: Some technologies allow the site to function. These functional cookies are required to use the site and complete purchases. Another set of technologies improve the browsing experience and personalize it. Here are all the details about Newegg’s Cookie and Privacy Policies. Please select and accept your settings before you continue. Thank you.

Your Personal Data

To use this third-party content we need your approval to share your data with them. Here are all the details about Newegg’s Cookie and Privacy Policies. Please accept if you wish to continue with third-party features. Thank you.
