Primary Ports: 1 x RJ45 Serial Port
5 x 10/100/1000 Ethernet Router Ports
1 x 1 Gbps SFP Ethernet Router Port
1 x USB 3.0 reserved for future
LEDs: Data Ports: Speed / Link / Activity, PoE
SFP Data Port: Link / Activity
Power: Max. Power Consumption: 16W (Excludes PoE Output)
Power Method: 24V, 2.5A Power Adapter (Included)
Power Supply: External AC Power Adapter, 60W (24V, 2.5A)
Supported Voltage Range: 100-240V AC, 50/60 Hz Universal Adapter 30-16V
Features: • 1 x 2.5G PoE++ port (Data + PoE out)
• 1 x 2.5G port (Data in)
• 95W PoE power budget
• Supports PoE (15.4W), PoE+ (30W), and PoE++ (95W)
devices
• Uses IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt industry
PoE standards for greater device interoperability
• Network a PoE device located up to 100m (328 ft.) away
• Fanless design eliminates operating noise and lowers energy
consumption
• Extreme operating temperature range - 40° — 75° C (-40° —
167° F)
• Redundant power inputs with overload current protection
• Includes DIN-Rail mount and wall mount
• Power supply sold separately (model: TI-S15052)
• NDAA / TAA compliant (U.S. only)
