Specifications: No. of Ports: 12
Pass Through Data Rates 10/100/1000 Mbps
PoE Output:
Pin Assignment and Polarity:
Data Pairs 1/2 (-) and 3/6 (+)
Spare Pairs 7/8 (-) and 4/5 (+)
Output Power Voltage: 54-57V DC
User Port Power: 72W Typ.
Aggregate Power: 1000W
Input Power Requirements:
AC Input Voltage: 100 to 240V AC
DC Input: 57V (RPS or another 9500G midspan)
AC Input Current: 450W Units: 5.5A @ 110V AC; 2.75A @ 220V AC
1000W Units: 12A @ 110V AC; 6A @ 220V AC
AC Frequency: 50 to 60 Hz
Management PowerView Pro included
Indicators:
System Indicator: AC Power (Green)
User Indicator: Channel Power (Green / Orange)
Connectors:
PoE ports and management port: Shielded RJ-45, EIA 568A and 568B
Console Port: USB Connector Type B
DC Connector: DC Block Terminal
RPS Com Connector: HD-D-sub-15
Specifications: Cable Type: Fiber Optic
Cable Length: 3.28 ft
Connector on First End: 1 x SFF-8431 SFP+
Connector on Second End: 1 x SFF-8431 SFP+
Device Supported: Network Device
Compatibility: Cisco 10GBASE SFP+ Modules
Certifications & Standards:
MSA
ELV
Wireless Data Rates: 802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
802.11n data rates on 2.4 GHz: 6.5 to 300 Mbps (MCS0-MCS15, HT 20/40)
802.11ac data rates on 5 GHz: 6.5 to 867 Mbps (MCS0-MCS9)
Interface: 1x Gigabit Ethernet uplink (10/100/1000BASE-T autosensing), PoE
3x Gigabit Ethernet local ports (10/100/1000BASE-T), including one PoE out port: PoE out provides 802.3af (Class 0) when access point is powered by 802.3at, or no output when powered by 802.3af
One passive pass-through port, RJ-45 (back to bottom)
Interface: 1 x 100/1000/2500 Base-T (Ethernet) Uplink Interface
3 x 10/100/1000 Base-T (Ethernet) Downlink Interface (LAN1,LAN2 and LAN3, LAN1 supports 10.5W PSE Power Budget)
Standards: IEEE 802.11ax
LEDs: Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors
Wireless Data Rates: 802.11b: 1, 2, 5.5, and 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
802.11n data rates on 2.4 GHz and 5GHz: 6.5 to 600Mbps (only 20 MHz and MCS 0 to MCS 15)
802.11ac data rates (5 GHz): 6.5 to 1733Mbps (MCS0-MCS9)
Interface: 2 x Gigabit (10/100/1000BASE-T autosensing), Power over Ethernet (PoE)
RJ-45 console port (not functional)
USB 2.0 (not functional)
