Specifications: Technical Information
Protection Type:
ESD Protection
Power Description
Input Voltage:
120 V AC
230 V AC
Maximum Output Voltage:
54 V DC
Maximum Input Current:
2.50 A
Maximum Output Current:
3.30 A
Maximum Output Power:
160 W
Interfaces/Ports
Output Ports:
4 x Multi-Gigabit PoE++
Physical Characteristics
Product Color:
Black
Form Factor:
DIN Rail/Wall Mountable
Height:
1.5"
Width:
2.8"
Length:
3.7"
Weight (Approximate):
9.80 oz
Miscellaneous
Package Contents:
PoE++ Injector
1 x Universal Power Adapter
1 x DIN Rail Mounting Kit
1 x Quick-Start Guide
Compatibility:
IP cameras
access control devices
remote kiosks (POSs)
wireless access points
PoE lighting
digital signage.
Certifications & Standards:
IEEE 802.3af
IEEE...
Specifications: Length: 9 ft
Connector: Power IEC 320 EN 60320 C13
Connector (Second End): Power IEC 320 EN 60320 C14
Rated Voltage: AC 100-250 V
Rated Current: 10 A
Specifications: What's in the box:
Digi Connect EZ Mini - serial server, 1-port, with accessories
Power supply - 12 V, 2.5 A (76000823)
DIN rail clip (76002095)
Specifications: Description: IEEE 802.3af PoE compliant or 48 VDC input from included AC power supply
Voltage: 100-240 VAC
Current: 1.0 / 0.4 A
Frequency: 50 / 60 Hz
Specifications: No. of Ports: 12
Pass Through Data Rates 10/100/1000 Mbps
PoE Output:
Pin Assignment and Polarity:
Data Pairs 1/2 (-) and 3/6 (+)
Spare Pairs 7/8 (-) and 4/5 (+)
Output Power Voltage: 54-57V DC
User Port Power: 72W Typ.
Aggregate Power: 1000W
Input Power Requirements:
AC Input Voltage: 100 to 240V AC
DC Input: 57V (RPS or another 9500G midspan)
AC Input Current: 450W Units: 5.5A @ 110V AC; 2.75A @ 220V AC
1000W Units: 12A @ 110V AC; 6A @ 220V AC
AC Frequency: 50 to 60 Hz
Management PowerView Pro included
Indicators:
System Indicator: AC Power (Green)
User Indicator: Channel Power (Green / Orange)
Connectors:
PoE ports and management port: Shielded RJ-45, EIA 568A and 568B
Console Port: USB Connector Type B
DC Connector: DC Block Terminal
RPS Com Connector: HD-D-sub-15
Specifications: No. of Ports: 1
Data Rates: 10/100/1000 Mbps
Power over Ethernet Output:
Pin Assignment and Polarity: 4/5 (+), 7/8 (-)
Output Power Voltage: 54V DC
User Port Power: 30 Watts (Guaranteed)
Input Power Requirements:
AC Input Voltage: 100 to 240V AC
AC Input Current: 0.8A @ 100-240V AC
AC Frequency: 50 to 60 Hz
Indicators:
AC Power (Yellow)
Channel Power (Green)
Connectors: Shielded RJ-45, EIA 568A and 568B
Thermal Rating: 20 BTU/Hr (@ 240V AC)
Regulatory Compliance:
IEEE 802.3af (PoE), RoHS Compliant,
WEEE Compliant, CE
