Specifications: xDirect232 Single Port RS232 10/100 Device Server
Serial Connectors: Single-port: DB9F RS232 (DCE Pinned)
Ethernet Interface: 10/100M RJ-45
Serial Interface Baud Rate: 300bps to 921.6 Kbps
LED Indicators: Power/Status, Link, Activity, Serial RX Activity & TX Activity
CPU: Based on DSTni-EX Enhanced 16-bit x86 Architecture
Memory: 256 KB SRAM, 1 MB Flash
100-240 VAC International Power Supply with Regional Adapters.
Specifications: What's in the box:
Digi Connect EZ Mini - serial server, 1-port, with accessories
Power supply - 12 V, 2.5 A (76000823)
DIN rail clip (76002095)
Specifications: 10/100/1000BASE-T (RJ-45) [100 m/328 ft.] to 1000BASE-SX 850nm multimode (SC) [62.5/125 µm fiber: 220 m/722 ft.]
Link Budget: 7.0 dB [50/125 µm fiber: 550 m/1804 ft.]
Standards: IEEE 802.3
Max Frame Size: untagged: 1632 bytes / tagged: 1628 bytes
Status LEDs:
PWR (Power): (below RJ-45)
ON = Lit for normal operation
FX-Link/Act (Fiber Link/Activity):
(Upper Left on RJ-45)
ON = Link; Flashing = Activity
TX-Link/Act (Copper Link/Activity):
(Upper Right on RJ-45)
ON = Link; Flashing = Activity
Power
Consumption: 3.15 Watts
Sources: Unit accepts 5 VDC to 28 VDC
Wall Mount AC adapter: 12 VDC 400mA
Environment
Storage: -15 to +65 °C
Operating: 0°C to 50°C
Altitude: 0 – 10,000 feet
Humidity: 5% to 95% (non-condensing)
Compliance
Safety: Wall Mount Power Supply, UL Listed,
C-UL Listed (Canada)
FCC Class A, CISPR22/EN55022...
Specifications: Dimensions: 3.80" x 1.20" x 0.90"
Output Interface:
3 x USB-A 3.0 Ports
1 x Gigabit Ethernet Port
Input Interface: 1 x USB-A 3.0 Connector
Chipset: RTL8153
Supported Systems: Windows (XP / Vista / 7 / 8 / 8.1 / 10), Mac OS X (10.5-10.11), Linux OS and Chrome OS
Package Contents:
USB 3.0 3-Port Hub & Gigabit Ethernet Adapter UE330
User Guide
Specifications: xDirect PoE Single Port RS232/422/485 10/100 Device Server w/o Power Supply
Serial Connectors: Single-port: DB9F (RS232/RS422/RS485, DCE Pinned)
Ethernet Interface: 10/100M RJ-45
Serial Interface Baud Rate: 300bps to 921.6 Kbps
LED Indicators: Power/Status, Link, Activity, Serial RX Activity & TX Activity
CPU: Based on DSTni-EX Enhanced 16-bit x86 Architecture
Memory: 256 KB SRAM, 1 MB Flash
*No Power Supply
Specifications: Standards:
IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3x
IEEE 802.3az
USB Type-C
USB 3.0
USB 2.0
USB 1.1
Interface:
1 x USB Type-C connector
3 x USB 3.0 ports
1 x Gigabit port
Maximum Data Rate:
Up to 2 Gbps (Gigabit port)
Up to 5 Gbps (USB port)
Special Features:
Compact form factor
Energy saving GREENnet technology
Flexible USB Type-C cable
USB Bus Powered:
Output: 5V, 0.9A
Consumption 4.5W (max.)
System Compatibility:
Windows: 10, 8.1, 8
MacOS: 10.9 - 10.13
Operating Temperature: 0 - 40 degree C (32 - 104 degree F)
Operating Humidity: Max. 90% non-condensing
Package Contents:
TUC-ETGH3
Quick Installation Guide
CD-ROM (Driver & User's Guide)
Specifications: Industry Standards:
IEEE 802.3af PoE, IEEE 802.3at PoE+
IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T
Ports: 4
Maximum Cable Length: 328 ft [100 m]
Maximum Data Transfer Rate: 2 Gbps (Full-Duplex)
MTBF: 50,000 Hours
Power Output: 52V DC at 30.8W (PoE+)
Connector Type(s): 8 - RJ-45 Female
Enclosure Type: Steel
LED Indicators: 1-Power, 4-PoE In-Use
Center Tip Polarity: Positive
Input Current: 2-1 A
Input Voltage: 100 ~ 240 AC
Output Current: 2.31 A
Output Voltage: 52 DC
Plug Type: M
Power Consumption: 120 W Max
Power Source: AC Adapter Included
Included in Package:
1 - 4 Port Gigabit PoE+ Injector
1 - Universal Power Adapter
3 - Power Cords (NA/UK/EU)
1 - Instruction Manual
Specifications: Cable Type: Twinaxial
Cable Length: 4.92 ft
Connector On First End: 1 x SFP+ Network
Connector On Second End: 1 x SFP+ Network
Device Supported: Network Device
Data Transfer Rate: 1.25 GB/s
