TP-Link TL-ANT2424MD 2.4 GHz 24dBi 2x2 MIMO Dish AntennaType: AntennaSpecifications: Frequency: 2.3 ~ 2.7GHz
Impedance: 50O
Gain: 24 dBi (Exclude Cable Loss)
VSWR(MAX.): 1.8
HPOL Beamwidth: 6 degree (3dB)
VPOL Beamwidth: 6 degree (3dB)
Elevation Beamwidth: 6 degree (3dB)
Polarization: Horizontal & Vertical
Mounting: Pole Mount
F/B Ratio: 32dB Min
Survival Wind Speed: 241 Km/h
Standards: RoHS, WEEE
Interfaces: RP-SMAModel #: TL-ANT2424MD
Quick View
TP-Link TL-ANT2403N 2.4GHz 3dBi Wireless N Desktop AntennaType: AntennaSpecifications: Frequency: 2.4GHz~2.5GHz
Gain: 3dBi
Radiation: Omni-directional
VSWR(MAX.): 1.92:1 MAX
Polarization: Linear, Vertical
Connector Type: RP-SMA Male (Plug)
Extended Cable/Length: RG-174 100cm
Mounting: Desktop
Application: IndoorModel #: TL-ANT2403N
Quick View
CISCO AIR-ANT2524DW-R Dual-band Dipole Antenna for Cisco Aironet APs - WhiteType: AntennaColor: BlackSpecifications: Color: White
Antenna type: Dual-band dipole
Operating frequency range: 2400 to 2500 MHz; 5150 to 5850 MHz
Nominal input impedance: 50 Ohms
VSWR: Less than 2:1
Peak Gain @ 2.4. GHz: 2 dBi
Peak Gain @ 5 GHz: 4 dBi
Elevation plane 3dB beamwidth @2.4 GHz: 63 degrees
Elevation plane 3dB beamwidth @ 5 GHz: 39 degrees
Connector type: RP-TNC plug
Antenna length: 6.63"
Weight: 1.3 oz.
Environment: Indoor, officeModel #: AIR-ANT2524DW-R
Quick View
Open Box CISCO AIR-ANT2566P4W-R= Aironet 2.4-GHz/5-GHz MIMO 4-Element Patch AntennaType: AntennaColor: BlackSpecifications: Antenna type: 4-element dual-band MIMO
Operating frequency range:
2400-2484 MHz
5150-5850 MHz
VSWR: 2:1 or less
Gain: 6 dBi in both bands
Polarization: Linear, vertical
Azimuth Plane 3-dB Beamwidth:
2.4 GHz band: 105 degree
5 GHz band: 125 degree
Elevation Plane 3-dB Beamwidth:
2.4 GHz band: 70 degree
5 GHz band: 60 degree
Length: 6.3 in. (16 cm)
Width: 11 in. (27.9 cm)
Depth: 1.2 in. (3.05 cm)
Weight: 1.4 lbs.
Cable length and type: 3 ft. (91.4 cm) plenum rated
Connector: RP-TNC
Environment: Indoor/outdoorModel #: AIR-ANT2566P4W-R=
Quick View
HP JW026A Aruba Antenna-2x2-5005 Pair 5G 5 dBi OmniType: AntennaSpecifications: Directivity: Omni-directional
Frequency: 4.90 GHz to 5.88 GHz
Antenna Gain: 5 dBi
Connector Type: N-Type
Form Factor: Direct / Pole Mount
Application / Usaage: Wireless Data Network
Application / Usage: Wireless Access Point
Package Contents: ANT-2x2-5005 Antenna, Pole Mount KitModel #: JW026A
Quick View
Ubiquiti Networks AF-5G34-S45 5Ghz Airfiber Dish 34Dbi Slant 45Type: AntennaSpecifications: Frequency: 5.1 - 5.8 GHz
Gain: 34 dBi
Max. VSWR: 1.4:1
Wind Survivability: 200 km/h (125 mph)
Wind Loading: 1,779 N @ 200 km/h (400 lb @ 125 mph)
Polarization: Dual Linear
F/B Ratio: 42 dB
ETSI Specification: EN 302 326 DN2
Dimensions: 41.34" x 16.60" x 41.34"
Weight: 29.80 lbs.Model #: AF-5G34-S45
