Wireless Data Rates: Supported Rates:
802.11be: 4 to 5765 Mbps
802.11ax: 4 to 4804 Mbps
802.11ac: 6.5 to 866 Mbps
802.11n: 6.5 to 300 Mbps
802.11a/g: 6 to 54 Mbps
802.11b: 1 to 11 Mbps
Frequency Band: ISM (2.4-2.484GHz)
U-NII-1 (5.15-5.25GHz)
U-NII-2A (5.25-5.35GHz)
U-NII-2C (5.47-5.725GHz)
U-NII-3 (5.725-5.85GHz)
U-NII-5 (5.925–6.425GHz)
U-NII-6 (6.425–6.525GHz)
U-NII-7 (6.525–6.875GHz)
U-NII-8 (6.875–7.125GHz)
Frequency Band: 2.4 GHz, 5 GHz
Performance: Maximum data rate (2.4 GHz): 1148 Mbps ¦ Maximum data rate (5 GHz): 4.8 Gbps
Capacity: Simultaneous VoIP clients: 60 ¦ SSIDs per radio: 16
Interface: 1 x 1000Base-T (PoE+) - RJ-45 ¦ 1 x USB 2.0 - Type A ¦ 1 x 1/2.5/5GBase-T (PoE+)
Frequency Band: RF
Operating frequency* 57–66 GHz
* Depends on regulatory region.
Channel bandwidth 2160 MHz/4320 MHz (With channel bonding enabled)
Operating channels 58320, 59400, 60480, 61560, 62640, 63720, 64800 MHz*
*Depends on the channel bandwidth.
Polarization Vertically linear
Beamwidth Azimuth: 3 dB 1.6°
Elevation: 3 dB 1.6°
Back-Up RF
Operating frequency*
US/CA
U-NII-1 5150 - 5250 MHz
U-NII-3 5725 - 5850 MHz
Worldwide 5150–5875 MHz
*Depends on regulatory region.
Channel bandwidth 20/40/80 MHz
Polarization Dual-linear
Beamwidth Azimuth: 3 dB 5°
Elevation: 3 dB 5°
LEDs: Power Flashing white: bootup in progress
White: not connected to UISP™ console
Blue: connected to UISP console
Ethernet Flashing blue: ethernet activity
GPS Blue: receiving at least (4) GPS satellite signals
60G Blue: active connection
5G Blue: active connecti...
Interface: E0: Ethernet wired network port (RJ-45)
USB 2.0 host interface (type A connector)
Serial console interface (proprietary, micro-B USB physical jack)
Kensington security slot.
Frequency Band: RF
Operating frequency* 57–71 Ghz
* Depends on regulatory region.
Channel bandwidth 2160, 1080 MHz
Polarization Vertically linear
Beamwidth Azimuth: 3 dB 1.6°
Elevation: 3 dB 1.6°
LEDs: Power Flashing white: bootup in progress
White: not connected to UISP application
Blue: connected to UISP application
Ethernet Flashing blue: Ethernet activity
GPS Blue: receiving at least (4) GPS satellite signals
60G Blue: active connection
Power Supply: Power method Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC only
Power supply 48V DC, 0.65A gigabit PoE adapter (Included)
Supported voltage range 44–54V DC
22–27V DC
Frequency Band: Frequency Band:
2.40 GHz
5 GHz
6 GHz
Indoor/ Outdoor:
Indoor
Wireless Transmission Speed:
7.80 Gbit/s
MIMO Technology:
Yes
MIMO Type:
Multi User MIMO
Beamforming Technology:
Yes
Data Encryption:
Yes
Encryption Standard:
WEP
WPA
WPA2-PSK
WPA3
WPA3-ENT
WPA2
Interface: Ethernet Technology:
2.5 Gigabit Ethernet
Gigabit Ethernet
Number of Network (RJ-45) Ports:
2
PoE PD Port:
Yes
Wi-Fi Generation:
Wi-Fi 6E
Communication Protocols:
RADIUS
SNMP
Wireless Performance:
AXE7800
Part Number: WAX640S-6E
Standards: Wireless LAN Standard:
IEEE 802.11 a/b/g/n/ac/ax
Network Band:
Tri Band
