Type: 4-Port Industrial USB to RS-232/422/485 Serial Adapter
Color: Black
Changer Type: USB to RS-232/422/485 Serial
Specifications: Converts a single USB port into four RS232/RS422/RS485 serial ports over USB 2.0 with four modes: RS232, RS422, 4-wire and 2-wire RS485
15 kV ESD protection (Level 4) against noise emissions and electrical voltage surges
DIN rail and wall mountable
Rugged IP30 rated metal hub housing and screw-locking host connection, ideal for harsh industrial environments
Data transfer baud rate up to 921.6Kbps
COM port expansion with COM retention
Powered by USB, and features plug-and-play installation
Specifications: Interfaces
Serial
4 x Programmable Bi-directional RS-232/422/485 Port
(4 x DB9 Male Connector, configurable via pin assignments);
Baud Rate: 300 to 115200 (default: 9600);
Data Bit: 8 (default) or 7;
Stop Bit: 1 (default) or 2;
Parity: None (default), Even or Odd;
Flow Control: None (default) RTS/CTS
Ethernet
1 x RJ-45 Female, 10/100Base-T
Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH
DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds:
IP: 192.168.0.60
Subnet Mask: 255.255.255.0
Switches
Controller ID: 1 x 16-segment Switch
Expander ID: 1 x 8-segment Switch
Reset Button: 1 x Semi-recessed Pushbutton
USB: 1 x USB Type A
Power: Consumption 5 VDC, 7.5 W(adapter) ; 48VDC, 9.5 W(PoE, PoE 802.3 AF/AT compatibility)
Changer Type: Product Type: RocketPort Universal PCI Quad DB9 Multiport Serial Adapter
Host Interface: Universal PCI
Data Transfer Rate: Up to 460.80 Kbps
Ports Expandability: 4 x 9-pin DB-9 Male RS-232 - Serial, Via Cable (Optional)
Specifications: Product Type: RocketPort EXPRESS Quadcable DB9 Multiport Serial Adapter
Host Interface: PCI Express x1
Data Transfer Rate: Up to 921 Kbps
Ports Expandability: 4 x 9-pin DB-9 Male RS-232/422/485 - Serial, Via Cable (Included)
