Specifications: Interfaces
IR/Serial 6 x Programmable IR / Uni-directional RS-232 Port
6 x 2-Pole Terminal Block Connector
IR: TTL level (0 to 5 V)
Carrier Frequency: 10 - 455 KHz;
Serial: Uni-directional RS-232 ( + - 5 V)
Baud Rate: 300 to 115200 (default: 9600);
Data Bit: 8 (default) or 7;
Stop Bit: 1 (default) or 2;
Parity: None (default), Even or Odd
Ethernet
1 x RJ-45 Female, 10/100Base-T
Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH
DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds:
IP: 192.168.0.60
Subnet Mask: 255.255.255.0
Switches
Controller ID: 1 x 16-segment Switch
Expander ID: 1 x 8-segment Switch
Reset Button: 1 x Semi-recessed Pushbutton
USB: 1 x USB Type A (Firmware upgrade only)
Power: Consumption 5VDC, 8W(adapter); 48V, 10.5W (PoE, PoE 802.3 AF/AT compatibility)...
Specifications: Video
Standards: HDMI 1.3; HDCP 1.2
Maximum pixel clock: 165MHz
Maximum data rate: 6.75Gbps
Resolution: 1920X1080P@60Hz
Connector: HDMI-A
Impedance: 100O
IR
Interface: 3.5mm seat
Signal direction: directional
Signal type: Digital
IR frequency: 20~60 KHz ;
UTP
Interface: RJ45/IEEE-568B
Transmission distance: CAT5e:50m/164ft,CAT6:60m/ 196ft
Other
Power supply: The power adapter: DC 5V/1A
Power dissipation: MAX 3W
Temperature: Operating: -5? ~ +70?
Humidity: Operating: 5% ~ 90%
Dimension: 94*71*25mm
The warranty: 1 year free warranty
