Specifications: NEW 60M HDMI KVM Over Network Extender 1080P HDMI Transmitter by RJ45 CAT5e CAT6 Extensor Support KVM remote control
Video
Standards: HDMI 1.4b; HDCP 1.4 and DVI compliant
Maximum pixel clock: 300MHz
Maximum data rate: 10.2Gbps
Resolution: 1920X1080P@60Hz
Connector: HDMI-A
Impedance: 100O
Package Contents: HDMI KVM extender transmitter x1
HDMI KVM extender receiver x1
Power adapter x1
User manual x1
Specifications: Function
Operating System Requirements
Windows Windows Vista, Windows 7, Windows 8, Windows 8.1
Mac Mac OS X10.3+
USB Specification USB 2.0
Cable Connections
Input Transmitter: USB Type B Female x 1; Receiver: RJ45 Ethernet Connector
Output Transmitter: RJ45 Ethernet connector; Receiver: USB Type A Female x 4
Transfer Rate Up to 480 Mbps
Cable Length Transmitter: USB cable 1ft (included); Receiver: Cat 5, Cat 5e or Cat 6 cable (not included) up to 164ft (50m)
Cable Distance Maximum cable distance from Transmitter to Receiver: 164ft (50m)
Cable Type Ethernet Cat 5, Cat 5e or Cat 6 required for connection between receiver and transmitter.
Connectors
AC Power Inlets Barrel type
Max Output Power 500mA @ 5V
Power Supply 2A @ 5VDC
LEDs
Power On
Operating Te...
Specifications: NEW 60M HDMI KVM Over Network Extender 4K 60Hz HDMI Transmitter by RJ45 CAT5e CAT6 Extensor Support KVM remote control
Video
Standards: HDMI 2.0; HDCP 2.2 and DVI compliant
Maximum pixel clock: 300MHz
Maximum data rate: 18Gbps
Resolution: 3840 x 2160@60Hz
Connector: HDMI-A
Impedance: 100O
?
Package Contents: HDMI KVM extender transmitter x1
HDMI KVM extender receiver x1
Power adapter x1
User manual x1
Specifications: NEW 60M HDMI KVM Over Network Extender 1080P HDMI Transmitter by RJ45 CAT5e CAT6 Extensor Support KVM remote control
Video
Standards: HDMI 1.4b; HDCP 1.4 and DVI compliant
Maximum pixel clock: 300MHz
Maximum data rate: 10.2Gbps
Resolution: 1920X1080P@60Hz
Connector: HDMI-A
Impedance: 100O
Package Contents: HDMI KVM extender transmitter x1
HDMI KVM extender receiver x1
Power adapter x1
User manual x1
Specifications: NEW 60M HDMI KVM Over Network Extender 1080P HDMI Transmitter by RJ45 CAT5e CAT6 Extensor Support KVM remote control
Video
Standards: HDMI 1.4b; HDCP 1.4 and DVI compliant
Maximum pixel clock: 300MHz
Maximum data rate: 10.2Gbps
Resolution: 1920X1080P@60Hz
Connector: HDMI-A
Impedance: 100O
Package Contents: HDMI KVM extender transmitter x1
HDMI KVM extender receiver x1
Power adapter x1
User manual x1
Specifications: Cabling: Cat 5 UTP or better
Ports: 1
Max Distance: 50 m / 165 ft
Maximum Data Transfer Rate: 480Mbps
MTBF: 72,000 Hours
OS Compatibility: OS Independent; No additional drivers or software required
System and Cable Requirements:
A host computer with an available USB-A port (USB Type-A)
Terminated RJ45 Cat5e or better Ethernet cable
LED Indicators: 1 x Power / Link
Center Tip Polarity: Positive
Input Current: 0.6 A
Input Voltage: 100 - 240 AC
Output Current: 2 A
Output Voltage: 5 DC
Plug Type: N
Power Consumption (In Watts): 10
Power Source: AC Adapter Included
Enclosure Type: Steel
Specifications: The 4-Port USB 2.0 Over Cat5/Cat6 Extender is a perfect solution for conference rooms and huddle spaces in need of a innovatively simple, yet powerful solution for extending USB signals beyond their native 16.4 foot length limitation.
Convenience
Plug and play installation is quick and easy with no software or drivers required. Reduce cable clutter by running a single Cat5/Cat6 cable to a remote location, or for added convenience, use existing in-wall Cat5/Cat6 cabling to extend USB connections between rooms.
Performance
Using USB 2.0 speed and power, this solution provides increased bandwidth and faster data transfer speeds, up to 480Mbps, over standard Cat5/Cat6 cabling at lengths up to 150ft. The included 5V2A DC power supply, which is required to be...
Specifications: The 1-Port USB 2.0 Over Cat5/Cat6 Extender is a perfect solution for conference rooms and huddle spaces in need of a innovatively simple, yet powerful solution for extending USB signals beyond their native 16.4 foot length limitation.
Convenience
Plug and play installation is quick and easy with no software or drivers required. Reduce cable clutter by running a single Cat5/Cat6 cable to a remote location, or for added convenience, use existing in-wall Cat5/Cat6 cabling to extend USB connections between rooms.
Performance
Using USB 2.0 speed and power, this solution provides increased bandwidth and faster data transfer speeds, up to 480Mbps, over standard Cat5/Cat6 cabling at lengths up to 150ft. The included 5V2A DC power supply provides enough power to...
Specifications: Long-Distance Data Transfer to 1 Device—Up to 164 ft. (50 m) from the Source
Send data to a USB 2.0 device located up to 164 ft. from the source
USB signals travel over a single user-supplied Cat5/Cat6 cable
Includes transmitter with built-in USB-A cable and a 1-port receiver
Supports data transfer rates up to 480 Mbps
Greater Distance over Cat5/Cat6 Cable Provides Greater Flexibility
Cat5/Cat6 cabling exceeds the 16 ft. distance limitation of USB cables
Allows connection to devices that lack network connectivity in areas beyond the reach of standard USB cables
Makes connections in areas without network availability
Allows source to be in a secure location, separate from peripherals
Cat5/Cat6 cabling is cost-effective and readily available
For best resul...
Specifications: Long-Distance Data Transfer to 4 Devices - Up to 164 ft. (50 m) from the Source
Send data to as many as four USB 2.0 devices located up to 164 ft. from the source
USB signals travel over a single user-supplied Cat5/Cat6 cable
Includes transmitter with built-in USB-A cable and 4-port receiver hub
Supports data transfer rates up to 480 Mbps
Greater Distance over Cat5/Cat6 Cable Provides Greater Flexibility
Cat5/Cat6 cabling exceeds the 16 ft. distance limitation of USB cables
Allows connection to devices that lack network connectivity in areas beyond the reach of standard USB cables
Makes connections in areas without network availability
Allows source to be in a secure location, separate from peripherals
Cat5/Cat6 cabling is cost-effective and readily avai...
