Specifications: Audio Specifications: HDMI output - 7.1 surround sound; DVI output - 2-channel stereo audio
General Specifications: Only one video output is supported on the video adapter at a time. If multiple connections are made, only one of the outputs will function.
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: 3840 × 2160
Maximum Power Delivery Support: None
Supported Resolutions: HDMI output: 3840 x 2160 (@ 30 Hz), 2560 x 1600, 2048 x 1280 (@ 60 Hz), 1920 x 1200, 1920 x 1080, 1280 x 720; VGA and DVI output: 1920 x 1200 (@ 60 Hz), 1920 x 1080, 1280 x 720
Video Revision: DisplayPort 1.2
Wide Screen Supported: Yes
Output Connector: 1 x HDMI (19 pin) Female Output
1 x DVI-I (29 pin) Female Output
1 x VGA (15 pin, High Density D-Sub) Female Output
Specifications: Active or Passive Adapter: Active
Adapter Style: Adapters
AV Input: USB Type-C
AV Output: HDMI / DVI-D / VGA / Mini-DisplayPort
Chipset ID:
Parade - PS176
VIA/VLI - VL102
ITE -IT6516
Audio Specifications: HDMI or mDP output: 7.1 surround sound
Maximum Analog Resolutions: 1920 x 1200 @ 60Hz
Maximum Digital Resolutions:
4096 X 2160 @ 24Hz or 3840 X 2160 @ 60Hz (HDMI)
4096 X 2160 @ 60Hz (mDP)
Supported Resolutions:
Maximum HDMI output: 4096 X 2160 @ 24Hz or 3840 X 2160 @ 60Hz
Maximum mDP output: 4096 X 2160 @ 60Hz
Maximum DVI and VGA output: 1920 x 1200 @ 60Hz
Lower resolutions and refresh rates may also be supported
Video Revision: HDMI 2.0 / DisplayPort 1.2
Wide Screen Supported: Yes
Note: On...
Specifications: Audio: Yes
Chipset ID: NXP - PTN5100 / Pericom - PI3DPX1203
Converter Type: Format Converter
Audio Specifications: 7.1 surround sound
Maximum Digital Resolutions: 4K (3840 x 2160) @ 60 Hz
Supported Resolutions:
1024 x 768
1280 x 720
1920 x 1080 @ 144hz
1920 x 1200
2560 x 1440
2560 x 1600
3840 x 2160 @ 60Hz
Video Revision: DisplayPort 1.2
Wide Screen Supported: Yes
Connector:
1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
1 x Mini-DisplayPort (20 pin) Female Output
System and Cable Requirements:
Your USB-C device must support DisplayPort over USB-C (DP alt mode) to work with this adapter
This adapter outputs a single-mode Mini DisplayPort signal and will not work with additional video adapters such as Mini DisplayPort to HDMI, Mini DisplayPor...
Specifications: Specification
1.Model: WL-UG7702H-A
2.Ports: Front: 3*HDMI port(4K@60Hz), 1*HDMI port(DP Alt Mode converted to HDMI) (4K@144Hz)
3.Rear: USB-C port(PD IN 140W), USB-C connector(PD pass-through 130W Charging)
4.Unit Size: LxWxH: 11.4x7x1.5 cm/4.5x2.8x0.6 inch
5.USB-C Cable Length: 25.6 cm/10.4 inch
6.Unit Weight: 132g/4.7oz
7.Material: Aluminum Alloy
Features: - Comes with 4*HDMI ports; this display adapter supports 3*4K@60Hz+1*4K@144Hz display output.
- 1 x PD port supports PD pass-through, power in 140W (PD3.1), and charges the laptop at 130W max.
- 1 x USB 3.2 Gen2 (10G) port and a strong, powerful GPU ensure stable video transmission.
- Video display using the SiliconMotion chip solution supports laptops including Thunderbolt 4/3, USB 3.1/3.0, and legacy USB-A port laptops.
