Specifications: Battery Rechargeable: Yes
Battery Chemistry: Nickel-Metal Hydride (NiMH)
Battery Capacity: 3500 mAh
Output Voltage: 7.2 V DC
Maximum Battery Run Time: 16 Hour
Weight (Approximate): 11 oz
Specifications: Pro3000 Analog Toner Specifications
User interface:
Slide switch selects Continuity or Tone Mode
Push button switch selects SOLID, ALT or OFF
Tone mode LED
Continuity/Polarity LED
Solid Frequency: 1000 Hz nominal
Alternating Frequency: 1000/1500 Hz nominal
Over Voltage Protection: 60 Vdc in Toner/Polarity Mode
Output Power in Tone Mode: 8 dbm into 600 ohms
Output Voltage Level in Continuity Mode: 8 Vdc with fresh battery
Battery: 9V alkaline
Temperature: Operating: -20° C to 60° C, Storage: -40° C to 70° C
Pro3000 Analog Probe specifications
User interface:
ON/OFF pushbutton
Volume dial
Replaceable tip
3.5 mm earphone jack
Battery: 9V alkaline
Temperature: Operating: -20° C to 60° C, Storage: -40° C to 70° C
Specifications: Included in Package: Black leather holder
Instruction Manual
Remote Cable Tester
LED Indicators: Battery condition
Center conductor
Conductor indicators
Connected or 25 Ohm detected
No cable / No terminator
Non-parallel or 50 Ohm detected
Shielding
Short circuit detected
Product Height: 25 mm [1 in]
Product Length: 180 mm [7.1 in]
Product Weight: 250 g [8.8 oz]
Product Width: 110 mm [4.3 in]
Shipping (Package) Weight: 0.4 kg [0.9 lb]
Specifications: Test Services:
Detects IntelliTone digital signal and 1 kHz signal from analog toners.
Features a CABLEMAP capability that identifies common cable miswires such as opens, shorts, and reversed pairs in twisted pair cabling.
Ports: 1 x RJ-45 10/100Base-TX Network
Connectivity Media:
Twisted Pair
Coaxial
10/100Base-TX
Status Indicators:
8 LED indicators
1 Synch LED indicator
Batteries: Alkaline Battery
Battery Life: 20 Hour Typical
Input Voltage: 9 V DC Battery
Temperature:
32°F (0°C) to 104°F (40°C) Operating
-4°F (-20°C) to 140°F (60°C) Storage
Dimensions: 8.73" x 1.88" x 1.26"
Package Contents:
IntelliTone 200 Probe
RJ-11 and RJ-45 patch cables
Lanyard
Owners CD
Quick start guide
9 volt battery
Additional Information: POTS telecom service available
Altitude: 3000 m
Operating Relative Humidity:
95 % (50 °F to 95 °F ; 10 °C to 35 °C)
75 % (95...
Specifications: Our most economical do-everything toolkit. The Essential Electronics Toolkit is what you need for the most essential electronics repairs—like screen and battery swaps—and everything you need for most household DIY fixes. Get started in electronics repair with all the bits and precision tools to handle your most urgent screen breaks and battery swaps. Or simply upgrade your home DIY toolkit with what you need to service door knobs, home appliances, eyeglasses, and more.
Specifications: Test Services:
Fault Display
High Speed Testing
Generation of two tones for tracing cables and locating hidden cables
Length Measurement:
15.75" to 656 ft Twisted Pair
Ports: 1 x RJ-45
Status Indicators:
5 green LEDs for pairs and shield display
6 red LEDs (TONER, SHORT, REVERSED, MISWIRE, SPLIT PAIRS, and LOW BATTERY)
Batteries: Alkaline AAA
Features
Features
Auto-sleep mode
Generation of two tones for tracing cables and lication hidden cables
Packaging
Package Contents
MicroMapper MT-8200-49A Network Testing Device
MicroMapper Remote
Patch Cable
6-Volt Alkaline Battery
User Guide
The MicroMapper quickly and easily tests twisted pair cabling, giving you visibility of opens, shorts, crossed, reversed and split pairs. Just push the TEST button and MicroMapper will automatically scan all wire pairs for any existing faults...
Features: WIRE TRACING MULTIFUNCTION - Fast to locate the breakpoint without wire's cover damage, Find wire on all types of connected operating Ethernet switch /Router/PC terminal. Perfect for tracking RJ11, RJ45, cables or other metal wire (via adapter);And also with the Battery(10V-110V) positive and negative measurements function.(Note: The receiver only has
Package Contents: 1x Emitter with double RJ11 RJ45 interface, 1x Receiver with BNC interface,1x Pair of Earphone ,1x RJ11 Clip Adapter Cable,1x RJ45 Cable,1x Storage Box,2 batteries,1x English User Manual
