Specification: Compatible Devices:
HyperDeck Studio Recorder, UltraStudio Pro & 3D Capture and Playback devices, ATEM Studio Converter, Blackmagic Cinema Camera 2.5K (EF/MFT models), SmartView Duo and HD Monitors, ATEM Television Studio Production Switcher, SmartScope Duo 4K, and Blackmagic Production Camera 4K.
Input:
100 to 240 VAC, 50/60 Hz, 67 to 92 VA, 0.8 A
Output:
12 V, 2.5 A
Power:
30W
Power Supply: 12 V power supply included with international socket adapters for all countries
Specification: Contact Closure: 25 pin D-type connector providing 8 up to isolated inputs and 8 relay contact closure outputs
Inputs: Optical isolators triggered by connection to ground (maximum 5 V @ 14 mA)
Outputs: Mechanical relay contact closure to ground (maximum 30 V @ 1 A)
Ethernet: 10 / 100 BaseT with loop through for connecting to other Ethernet enabled equipment
Computer Interface: 1 x USB 2.0 high speed interface for configuration and firmware updates
Software Included: Configured via ATEM Switcher utility
Firmware Upgrade: Firmware built into software driver. Loaded at system startup or via updater software
Operating System: Microsoft Windows 7 and Apple Mac OS X
Feature: Displays Tallies for Video Signals
Indicates On-air ...
