Distance: up to 200 ft. at 1024 x 768 (60Hz)
up to 150 ft. at 1920 x 1080 (60Hz)
Color: Black
LED Indicator: The Green RJ45 LED on the local unit illuminates to indicate it is connected to and receiving power from the source. The Orange RJ45 LED on the local unit does not illuminate. The Green RJ45 LED on the remote unit illuminates to indicate it is receiving power from the external power supply. The Orange RJ45 LED on the remote unit illuminates to indicate it is connected to the local unit and receiving a signal from the source.
Specification: 1.Model: WL-UG7500H
2.Chip: DisplayLink DL7400-N
3.Connection to Host: PCIE 3.0 x4
4.Video Ports: 4 x HDMI
5.Operating Systems: Windows 10/11 or later, Ubuntu
6.Host Requirement: Desktop with at least one available standard PCIe x4/x8/x16 slot
7.Product Size: 12.4 x 12.1 x 2.2cm/4.9 x 4.8 x 0.9in (L x W x H)
8.Product Weight: 95g/3.4oz
Feature: - Four HDMI ports support max. 4K@60Hz display.
- Standard PCIe 3.0 x4 compatibility with most PCIe slots.
- Simple installation process; no complex configuration required.
Specification: OVERVIEW
Display Style: Extender
Model Type: VGA
Cable Types: CAT5/CAT5E
PHYSICAL
Included Mounting Accessories: Yes
ENVIRONMENTAL
Operating Temperature Range: 0 to 40 C (32 to 104 F)
Storage Temperature Range: -20 to 60 C (-4 to 140 F)
Relative Humidity: 20 to 90%
CONNECTIONS
Connector A: HDMI (FEMALE) (X4)
Connector B: RJ45 (FEMALE) (X4)
Feature: Tripp Lite's B126-4X4 HDMI over Cat5/6 Matrix Splitter Switch and Transmitter Unit allows you to share high-definition video and audio from four HDMI-enabled digital video components (e.g., DVR, Cable Box, Blu-Ray, HD gaming consoles, etc.) to four different monitors. When used with Tripp Lite Active HDMI receivers, it can extend
Distance: Max Distance: 70m (230 ft.)
Maximum 1080p Distance: 70m (230 ft.)
Maximum 4K Distance: 35m (115 ft.)
Resolution Support: 4K x 2K (Ultra HD) @ 30 Hz
2560 x 1600 @ 60 Hz
1920 x 1200
1920 x 1080 (1080p)
1280 x 720 (720p)
Power Consumption: 64.8W
Power Supply: Center Tip Polarity: Positive
Input Current: 1.5A
Input Voltage: 100 ~ 240 AC
Output Current: 2.7A
Output Voltage: 24 DC
Plug Type: 4-pin DIN
Power Source: AC Adapter Included
Specification: Color: Black
Maximum Resolution: 1080p @ 60Hz
HDMI Version: HDMI 1.2
Power: 5V DC
HDCP: Yes, HDCP 1.1
DVI Version: DVI 1.0
Ports In:
1 x 3.5mm analog audio (two channel)
1 x Digital Coax Audio
3 x Component RCA (YPbPr/YCbCr)
Ports out:
1 x HDMI Connector
Feature: Compliant with HDMI 1.2/HDCP 1.1/DVI 1.0
Supports a maximum resolution of 1080p
Supports digital and analog audio input
Supports stand and high definition video output
