Specification: Maximum Pixel Clock: 2x 165 MHz
Video Input Connector: (1) DVI-I 29-pin, female
Video Output Connector: (1) DVI-I 29-pin, female
Operating temperature range: +5 to +45 deg. Celsius
Power Supply: 5V DC (needed for programming only)
Power Consumption: 5 Watts (max)
Feature: Quick and easy way to store EDID information from any DVI display
Provides a virtual EDID to maintain active monitor status when switching away from a source
Supports resolutions up to 1920x1200, 2K, and 3840x2400 (Dual Link)
EDID write protection switch
No power is required after initial programming
Distance: Max 1024 x 768 Range (ft.): 100
Max 480P Range (ft.): 100
Max 1440 x 900 Range (ft.): 100
Max 1080i Range (ft.): 100
Max 1080P Range (ft.): 50
Max 480i Range (ft.): 100
Max 640 x 480 Range (ft.): 100
Max 800 x 600 Range (ft.): 100
Max 1600 x 1200 Range (ft.): 100
Max 720P Range (ft.): 100
Network Interface: Side A: RJ45 (FEMALE)
Side B: RJ45 (FEMALE)
VGA: Side A: 2 x HD15 (FEMALE)
Side B: HD15 (FEMALE)
Analog Aduio: Side A: 2 x 3.5MM (FEMALE)
Side B: 3.5MM (FEMALE)
Specification: COMMUNICATIONS
Max 1024 x 768 Range (ft.): 1000
Max 480P Range (ft.): 1000
Max 1440 x 900 Range (ft.): 500
Max 1080i Range (ft.): 500
Max 1080P Range (ft.): 500
Max 1920 x 1440 Range (ft.): 500
Max 480i Range (ft.): 1000
Max 640 x 480 Range (ft.): 1000
Max 800 x 600 Range (ft.): 1000
Max 1600 x 1200 Range (ft.): 500
Max 1920 x 1200 Range (ft.): 500
Max 720P Range (ft.): 500
Distance: up to 200 ft. at 1024 x 768 (60Hz)
up to 150 ft. at 1920 x 1080 (60Hz)
Color: Black
LED Indicator: The Green RJ45 LED on the local unit illuminates to indicate it is connected to and receiving power from the source. The Orange RJ45 LED on the local unit does not illuminate. The Green RJ45 LED on the remote unit illuminates to indicate it is receiving power from the external power supply. The Orange RJ45 LED on the remote unit illuminates to indicate it is connected to the local unit and receiving a signal from the source.
Distance: 4K@60Hz Up to 230ft/70M via Cat6/7 cable
Resolution Support: Up to 3840x2160 @60Hz
Audio: PCM 7.1 / DTS-HD / Dolby Digital 5.1ch via HDMI and 3.5mm stereo audio from receiver
HDMI: Transmitting unit (TX):
1x 19-pin HDMI, Type A, Female, Input
1x 19-pin HDMI, Type A, Female, Loop out
Receiving unit (RX):
1x 19-pin HDMI, Type A, Female, Output
