Specification: Dimension: 5.58" x 4.06" x 1.23"
Weight: 0.93 lbs.
1 x HDMI Type A Female (Black)
1 x LC Simplex Connector (SFP)
1 x captive screw connector, 3 pole
1 x 3.5mm phone jack (Black)
1 x DC Jack (Black)
600 m with single mode (SM) fi ber
Wavelength: 1310/1550 nm for SM
Data rate: Single fi ber: 1080p/60Hz (24-bits,3.125G bps ), 720p/60Hz(24-bits,3.125G bps)
1 (Green) Power/Link LED
Power Consumption: DC5.3V, 2.4W
Metal Housing
Feature: Extends the transmission range of HDMI, IR and RS-232 signals using one fi ber optic cable
Very long distance transmission - up to 600m for VE882
HDMI (3D, Deep Color), HDCP compatible - signaling rates up to 3.125 Gbits
Superior video quality - up to 1080p@60Hz
FPGA design extends digital signals to longer distances
Uses one fiber optic cable...
Specification: Ports In:
1 x HDMI Female
Ports Out:
Video Output: 1 x HDMI Female
Audio Output: 1 x TOSLINK (Optical) / 1 x RCA (Coaxial) / 2 x RCA (Stereo)
1 x DC Jack
Console Connectors (Flash ROM Upgrade): 1 x 4-conductor 3.5 mm Jack
1 x (Green) Power On LED
Switches
Mode Selection: Audio Channel - 1 x Slide Switch / HDMI Audio On/Off - 1 x Slide Switch
F/W Upgrade: 1 x semi-recessed pushbutton
Power: 5.3 VDc/150 mA
Power Consumption: 0.8 W - 3 BTU / hr
Dimension: 7.9" x 3.2" x 1"
Weight: 1 lbs.
Feature: Repeats HDMI input signal up to 15 meters
Extracts HDMI audio signal and outputs as additional audio source
Supports optical / coaxial digital audio and analog stereo audio
HDMI and HDCP compatible
Super Video Quality - up to 1920x1080 (1080p)
Firmware upgradable
CH2/CH5...
