Specifications: Includes stand, CPU strap, buckle cover, VESA monitor mounting kit, cable ties
* Weight Capacity: 6 - 16 lbs. for display; total stand capacity = 37 lbs for combined weight of display, CPU, keyboard and mouse
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Meets tip test requirements of UL Specification 1678
Compatible with most 15" - 24" displays, and most small or ultra small form factor CPUs, notebook computers, and gaming consoles
Maximum CPU size = 14" H x 4" D (36 x 10 cm); minimum CPU size = 7" H x 1.8" D (18 x 4.6 cm). The CPU should be centered on the stand
Motion may be restricted when using 22" - 24" monitors in portrait mode
Removal of lock screw allows portrait to landscape rotation
Mounting Option: Two M4 threaded screw inserts are located at the bottom of ...
Specifications: Glide Wall Mount will be hidden behind display in most cases when used with screen size of 46" or greater; when used with screens smaller than 46", the mount may be visible
Mounting holes must fit within spacing range below:
Horizontal = 200 mm (min.) to 400 mm (max.)
Vertical = 100 mm (min.) to 400 mm (max.)
Includes low-profile lift module, mounting template, tilt brackets, installation and mounting hardware, cable management hardware
Specifications: Description: WorkFit-C Sit-Stand Workstation for Two LCD Monitors, Dual, with Mobile Cart Base (black/grey)
Includes cart, two (2) LCD mounts, crossbar, integrated worksurface, large stowable keyboard tray, cable storage box, CPU holder, four dual casters (two locking), hand-brake system
**** Maximum outside width of each display = 21.25" (54 cm)
* Weight Capacity: Maximum load on height-adjustment assembly = 32.5 lbs (14.7 kg). Includes weight of displays and keyboard in addition to contents on Worksurface and in Cable Storage Box. LCD mount capacity = 6-14 lbs (2.7-6.3 kg) each, 12-28 lbs (5.5-12.7 kg) total
*** Lift Range: LCDs/keyboard/worksurface adjust 20" (51 cm) in tandem; LCDs adjust 5" (13 cm) independently; maximum LCD height adjustment = 25" (63 cm)
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 1...
Specifications: LCD Size: <=24"
Capacity: 8-33 lbs
Mounting Standards: VESA FDMI MIS-D, 100/75 (hole pattern: 100 x 100 mm & 75 x 75 mm)
Monitor pans left/right up to 50° (varies per size of monitor)
Fold-down keyboard with built-in mouse pad surface
Keyboard tray extends out up to 5" (12.7 cm) inches when in use
Keyboard tray pans left/right up to 120°
Scanner and mouse holder integrated into the keyboard tray
Back-tilt keyboard tray adjustable (0 to -10 degrees)
Integrated cable management system can be configured on either side
Easy-to-clean exterior
Specifications: LCD Size: 37" - 55"
Capacity: 50 - 90 lbs
Lift: 20"
Tilt: 20 degree
Rotation: 90 degree P/L
Includes cart, display and pan assembly, lower main shelf, 4-inch (100 mm) casters (two locking), rear cable shelf, cable channel kit
Complies with UL Tip Standards 1667 and 1678
Rugged plastic-composite shelf conveniently attaches to cart at any height
Modular cable channel system is adaptable for various wiring configurations
Add the MMC Camera Shelf Kit to place adjustable camera shelf above the display (ordered separately)
CPUs attach safely to rear of cart with Universal CPU Holder accessory (ordered separately). Compatible with CPU sizes from 12" H x 3" D to 18" H x 8.5" D (300 x 80 mm to 460 x 220 mm)
Weight Capacity: main shelf = 30 lbs (13.6 kg); cable shelf = 5 lbs (2.2 kg); if MMC Video-Conferencing Kit is added, display we...
Specifications: Complies with UL Tip Standards 1667 and 1678
Rugged plastic-composite shelf conveniently attaches to cart at any height
Modular cable channel system is adaptable for various wiring configurations
Add the MMC Camera Shelf Kit to place adjustable camera shelf above the display (ordered separately); shelf is not compatible with the NF MMC LD, 24-190-057, when using the optional small LCD monitor pivot (includes 75 mm and 100 mm mounting holes), which is typically used with 25 lbs (11. 4 kg) to 36 lbs (16.3 kg) displays. As an alternative, the NF WideView cart, 24-189-055, does accommodate this size monitor and a camera shelf
CPUs attach safely to rear of cart with Universal CPU Holder accessory (ordered separately). Compatible with CPU sizes from 12" H x 3" D to 18" H x 8.5" D (300 x 80 mm to 460 x 220 mm)...
Specifications: Compatible Models: Displays 17 to 32"
Mounting-Hole Pattern: 75 x 75 to 100 x 100 mm
Load Capacity: 19.8 lb / 9 kg
Mounting Compatibility: Solid Wall / Single Stud
Adjustments: Swivel: 180° (-90 to 90°)
Tilt: -45 to 90°
Rotation: 360° (-180 to 180°)
Screen Pivot (Arm): 180° (-90 to 90°)
Orientation: Landscape, Portrait
Distance from Mounting Surface: 3.5 to 21.2" / 8.9 to 53.8 cm
