Memory Standard: DDR3 2000(O.C.)/ 1866/ 1600/ 1333/ 1066
* To support a DDR3 1866 MHz (and above) memory, you must install an AM3+ CPU first.
PCI Express 2.0 x16: 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x4 (PCIEX4)
* The PCIEX4 slot shares bandwidth with the M2F_10G connector. The PCIEX4 slot will operate at up to x2 mode when a PCIe SSD is installed in the M2F_10G connector.
Onboard Video Chipset: Integrated ATI Radeon HD 3000 GPU
Multi-VGA output support: HDMI/DVI/RGB ports *1
- Supports HDMI with max. resolution 1920 x 1200 @ 60 Hz
- Supports DVI with max. resolution 2560 x 1600 @ 60 Hz
- Supports RGB with max. resolution 2560 x 1440 @ 75 Hz
Maximum shared memory of 1024MB
Hybrid CrossFireX Support
*1: Support dual VGA output: HDMI & RGB, DVI & RGB.
Memory Standard: DDR3 2133(OC)/ 1866/ 1600/ 1333/ 1066** Due to CPU spec., AMD 100 series CPUs support up to DDR3 1066 MHz. With ASUS design, this motherboard can support up to DDR3 1333 MHz.
PCI Express 2.0 x16: 3 x PCIe 2.0 x16 (dual x16 or x16/x8/x8) *1
1 x PCIe 2.0 x16 (x4 mode, black)
*1: When running dual graphics cards, be sure to insert the card in the first and third PCIex16 slot to get the best performance.
Memory Standard: DDR3 2133(OC)/ 1866/ 1600/ 1333/ 1066*
* Due to CPU spec., AMD 100 series CPUs support up to DDR3 1066 MHz. With ASUS design, this motherboard can support up to DDR3 1333 MHz.
Memory Standard: DDR3 2000(O.C.)/ 1866/ 1600/ 1333/ 1066 (Note 2)
(Note 2) To support a DDR3 1866 MHz (and above) memory, you must install an AM3+ CPU first.
PCI Express 2.0 x16: 1 x PCI Express x16 slot, running at x16 (PCIEX16) (Note 3)
1 x PCI Express x16 slot, running at x4 (PCIEX4)
(Note 3) For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
PCI Express 2.0 x16: 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x4 (PCIEX4)
(All PCI Express slots conform to PCI Express 2.0 standard.)
