Specifications: Type: 3 Strip RGB LED Control Pack
Form Factor: Slim Profile
Voltage: 12V
LED Strips: (3) RGB Magnetic LED Strip
Mounting: 6 Neodymium Magnets + 3M Adhesive
LED Lights/Strip: 12
Fans Channels: 5
LED Modes: Flash Mode (Blue > Green > Red > White > Orange > Yellow > Purple) and 256 Color Fade Mode
Buttons:
Customize Button (256 Color Mode)
Mode Button (Color Select/Flash)
Brightness Button (Adjust Brightness Levels / Power On/Off)
LED Strip Chaining Capable: Yes
Power Connector: (1) 4-pin Fan Header
Weight: 145g
Color: Black
Dimensions: 80 x 60 x 20 mm
Specifications: The PWM ARGB hub is equipped with two connecting cables. 1.3FT Motherborad PWM RPM feedback cable include 2FT Motherboard 3pin ARGB cable include With wireless IR remote control for any 5V ARGB devices.No motherboard ARGB supporting is nneded Make sure remote using distance less than 6.6FT
Specifications: Material: 18 pcs 5050 RGB LED with magnetic strip and adhesive tape
Pin definition: +12V, G, R, B
Included Parts:
RGB LED strip x 2
Y cable x 2
Length: 300mm
Wattage: 1.44W (12V, 0.12A)
Tandem limits: 5 pcs on each line
Weight: 30g
Specifications: Material 12 pcs addressable RGB LED with magnetic strip and adhesive tape
Pin definition:
+5V, D, G*
+5V, D, NP, G*
Included Parts:
2 x Addressable RGB LED strip
1 x Motherboard connect cable**
1 x Splitter cable
Length: 300mm
Wattage: 3W (5V, 0.6A)
Tandem limits: Depend on controller
Remark:
* Please check the control box and motherboard pin header that you want to connect are the same as LS03’s pin definition.
** Included Motherboard connect cable supports SilverStone’s addressable RGB 3pin connectors and other market standard addressable RGB 3pin (three pin in four pin housing) connectors.
