PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E1)
- 1st, 2nd and 3rd Gen AMD Ryzen support x16 mode
- Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics support x8 mode
- Athlon with Radeon Vega Graphics support x4 mode
PCI Express 2.0 x16: 1 x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)*
* PCI_E4 will run x1 speed when installing devices in PCI_E2/PCI_E3/PCI_E5 slot.
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E1)
Supports x16 speed with 1st, 2nd and 3rd Gen AMD Ryzen processors
Supports x8 speed with Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with adeon Graphics processors
Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
PCI Express 2.0 x16: 1 x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)1,2
1. PCI_E2, PCI_E3, PCI_E4 and PCI_E5 slots will be unavailable when installing M.2 PCIe SSD in M2_2 slot.
2. PCI_E4 will run x1 speed when installing devices in any PCIe 2.0 x1 slot.
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E1)
Supports x16 speed with 1st, 2nd and 3rd Gen AMD Ryzen processors
Supports x8 speed with Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics processors
Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot:
Supports x16 speed with 1st, 2nd and 3rd Gen AMD Ryzen processors
Supports x8 speed with Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with adeon Graphics processors
Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
Onboard Video Chipset: Supported only by CPU with integrated graphic:
1 x DisplayPort, support a maximum resolution of 4096x2304 @60Hz, 2560x1600 @60Hz, 3840x2160 @60Hz, 1920x1200 @60Hz1,2
1 x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @30Hz, 2560x1600 @60Hz1,2
1. Only support when using Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics / Athl...
Memory Standard: For AMD Ryzen Gen3 (R5/R7/R9)
- Supports DDR4 4133/ 4000/ 3866/ 3733/ 3466/ 3200/ 3066/ 3000/ 2933/ 2800/ 2667 MHz by A-XMP OC mode*
For AMD Other CPU
- Supports DDR4 3466/ 3200/ 3066/ 3000/ 2933/ 2800/ 2667 MHz by A-XMP OC mode
Supports DDR4 2667/ 2400/ 2133/ 1866 MHz by JEDEC
* Please refer www.msi.com for more information on compatible memory.
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E1)
Supports x16 speed with 1st, 2nd and 3rd Gen AMD Ryzen processors
Supports x8 speed with Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics processors
Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E1)
Supports x16 speed with 1st, 2nd and 3rd Gen AMD Ryzen processors
Supports x8 speed with Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics processors
Supports x4 speed with Athlon with Radeon Vega Graphics Processors
PCI Express 2.0 x16: 1 x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)1,2
1. PCI_E2, PCI_E3, PCI_E4 and PCI_E5 slots will be unavailable when installing M.2 PCIe SSD in M2_2 slot.
2. PCI_E4 will run x1 speed when installing devic...
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E1)
Supports x16 speed with AMD Ryzen 1st and 2nd Generation processors
Supports x8 speed with AMD Ryzen with Radeon Vega Graphics processors
Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
Onboard Video Chipset: Supported only by CPU with integrated graphic:
1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
1 x HDMI 1.4 port, supports a maximum resolution of 4096x2160@30Hz, 2560x1600@60Hz
Only support when using AMD Ryzen with Radeon Vega Graphics / Athlon with Radeon Vega Graphics Processors
Maximum shared memory of 2048MB
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot
Supports x16 speed
- 1st, 2nd and 3rd Gen AMD Ryzen
Supports x8 speed
- Ryzen with Radeon Vega Graphics
- 2nd Gen AMD Ryzen with Radeon Graphics
- A-series
- Athlon X4
Supports x4 speed
- AMD Athlon with Radeon Vega Graphics
Onboard Video Chipset: Supported only by CPU with integrated graphic:
1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
1 x HDMI 2.0b with HDR port, support...
Memory Standard: Supports 3466/ 3200/ 3066/ 3000/ 2933/ 2800/ 2667 MHz by A-XMP OC mode, and DDR4 2667/ 2400/ 2133/ 1866 MHz by JEDEC
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E1)
Supports x16 speed with AMD Ryzen 1st and 2nd Generation processors
Supports x8 speed with AMD Ryzen with Radeon Vega Graphics processors
Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
Onboard Video Chipset: Supported only by CPU with integrated graphic:
1 x VGA port, supports a maximum resolution of 2048x1280@60Hz, 1920x1200@60Hz
1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
1 x HDMI 1.4 port, supporting a maximum resolution of 4096x2160@24Hz
Only support when using AMD Ryzen with Radeon Vega Graphics / Athlon with Radeon Vega Graphics Processors
Processors maximum shared mem...
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E1)
Supports x16 speed with 1st, 2nd and 3rd Gen AMD Ryzen processors
Supports x8 speed with Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics processors
Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E1)
- Supports x16 speed with 1st, 2nd and 3rd Gen AMD Ryzen processors
- Supports x8 speed with Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with adeon Graphics processors
- Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
PCI Express 2.0 x16: 1 x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)1,2
1. PCI_E2, PCI_E3, PCI_E4 and PCI_E5 slots will be unavailable when installing M.2 PCIe SSD in M2_2 slot.
2. PCI_E4 will run x1 speed when installing devices in any PCIe 2.0 x1 slot.
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot
- Supports x16 speed with AMD Ryzen 1st and 2nd Generation processors
- Supports x8 speed with AMD Ryzen with Radeon Vega Graphics processors
Onboard Video Chipset: Onboard Graphics:
- 1 x DVI-D port, support a maximum resolution of 1920x1200@60Hz*
- 1 x HDMI 1.4 port, supports a maximum resolution of 4096x2160@30Hz, 2560x1600@60Hz*
* Only support when using AMD Ryzen with Radeon Vega Graphics Processors
- Maximum shared memory of 2048MB
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot
Supports x16 speed with AMD Ryzen 1st, 2nd and 3rd Generation processors
Supports x8 speed with AMD Ryzen with Radeon Vega Graphics processors
Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
Onboard Video Chipset: Supported only by CPU with integrated graphic:
1 x DisplayPort, supports a maximum resolution of 4096x2160 @60Hz
1 x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @24Hz
Available for the processor with integrated graphics.
Memory Standard: Supports 3466/ 3200/ 3066/ 3000/ 2933/ 2800/ 2667 MHz by A-XMP OC mode, and DDR4 2667/ 2400/ 2133/ 1866 MHz by JEDEC
* Please refer www.msi.com for more information on compatible memory.
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E1)
1st, 2nd and 3rd Gen AMD Ryzen support x16 mode
Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics support x8 mode
Athlon with Radeon Vega Graphics support x4 mode
Onboard Video Chipset: Supported only by CPU with integrated graphic:
1 x VGA port, supports a maximum resolution of 2048x1280@60Hz
1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
1 x HDMI port, supports a maximum resolution of 4096x2160@24Hz
Only support when using Ryzen with Radeon Vega Graphics, 2nd Gen AMD Ryzen with Radeon Graphics and Athlon w...
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot:Supports x16 speed with AMD Ryzen 1st and 2nd Generation processorsSupports x8 speed with AMD Ryzen with Radeon Vega Graphics processorsSupports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
Onboard Video Chipset: Supported only by CPU with integrated graphic:1 x DisplayPort, support a maximum resolution of 4096x2304 @60Hz, 2560x1600 @60Hz, 3840x2160 @60Hz, 1920x1200 @60Hz1,21 x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @30Hz, 2560x1600 @60Hz1,2Only support when using AMD Ryzen with Radeon Vega Graphics / Athlon with Radeon Vega Graphics ProcessorsMaximum shared memory of 2048MB
