Features: High Performance Anti-Static wrist strap w/ grounding wire - Black and Yellow
Protect PC from Static Electricity: Eliminate static electricity from human body in 0.1s to protect your PC from static damage. The working principle of removing static electricity: Static electricity needs to be removed with a link wire with a
Package Contents: Anti-Static wrist strap w/ grounding wire - Black and Yellow
Specifications: Test Services:
Fault Display
High Speed Testing
Generation of two tones for tracing cables and locating hidden cables
Length Measurement:
15.75" to 656 ft Twisted Pair
Ports: 1 x RJ-45
Status Indicators:
5 green LEDs for pairs and shield display
6 red LEDs (TONER, SHORT, REVERSED, MISWIRE, SPLIT PAIRS, and LOW BATTERY)
Batteries: Alkaline AAA
Features
Features
Auto-sleep mode
Generation of two tones for tracing cables and lication hidden cables
Packaging
Package Contents
MicroMapper MT-8200-49A Network Testing Device
MicroMapper Remote
Patch Cable
6-Volt Alkaline Battery
User Guide
The MicroMapper quickly and easily tests twisted pair cabling, giving you visibility of opens, shorts, crossed, reversed and split pairs. Just push the TEST button and MicroMapper will automatically scan all wire pairs for any existing faults...
Specifications: Included in Package: Black leather holder
Instruction Manual
Remote Cable Tester
LED Indicators: Battery condition
Center conductor
Conductor indicators
Connected or 25 Ohm detected
No cable / No terminator
Non-parallel or 50 Ohm detected
Shielding
Short circuit detected
Product Height: 25 mm [1 in]
Product Length: 180 mm [7.1 in]
Product Weight: 250 g [8.8 oz]
Product Width: 110 mm [4.3 in]
Shipping (Package) Weight: 0.4 kg [0.9 lb]
Specifications: User interface
Slide switch selects Continuity or Tone Mode
Push button switch selects SOLID, ALT or OFF
Tone mode LED
Continuity/Polarity LED
Solid Frequency
1000 Hz nominal
Alternating Frequency
1000/1500 Hz nominal
Over Voltage Protection
60 Vdc in Toner/Polarity Mode
Output Power in Tone Mode
8 dbm into 600 ohms
Output Voltage Level in Continuity Mode
8 Vdc with fresh battery
Battery
9V alkaline
Temperature
Operating: -20° C to 60° C, Storage: -40° C to 70° C
Case dimensions
2.7 in. x 2.4 in. x 1.4 in. (6.9 cm x 6.1 cm x 3.6 cm)
Specifications: Electrical
Loop Limit
2.4 kOmaximum at 48 VDC (nominal 15 mA minimum loopcurrent)
DC Resistance (Talk Mode)
150 Otypical at 80 mA current
AC Impedance (Monitor Mode)
Low impedance (Ring position) 600 Oat 1 KHz typical
High impedance (HI Z position) 100 kOminimum at 1 KHz
Rotary Dial Output
10 pps .5 pps
Pulsing Rate 60 % ± 2 %
Percent Break 800 ms typical
Interdigit Interval Leakage During Break
> 50 kO
DTMF Output
±1 % maximum
Tone Frequency Error Level per Tone Pair
dBm maximum, - dBm minimum
High versus Low Tone Difference
4 dB maximum
Physical
Length
8.75 in (22.2 cm)
Width
2.375 in (6.03 cm)
Height
3.375 in (8.57 cm)
Weight
10.8 oz (.307 kg) maximum
Environmental
Temperature
Operating: -5 °C to °C
Storage: -40 °C to °C
Drop
1 meter, 4 times
Altitude
To 3,000 meters (10,000 feet) maximum
Relative Humidity
10 %to 80 % (non...
Specifications: Test Services:
Graphical wiremap, length, cable ID, and distance to fault displayed on one screen.
Tests all common media types including RJ11, RJ45, Coax, with no need for adapters.
Locates virtually any cable or wire pair with IntelliTone digital and analog toning.
Verifies today's media services, including 10/100/1000 Ethernet, POTS, and PoE.
Integrated rubber holster enhances grip and makes it durable enough for the toughest jobs.
Large, backlit LCD makes results crystal clear whether in bright sunshine or in a dark closet.
Length Measurement: 11.81" to 1509 ft
Ports: RJ-45 10/100/1000Base-T Network
Connectivity Media: UTP
Display Screen: Monochrome LCD with backlight
Batteries: AA Standard
Dimensions: 3.00" x 6.40" x 1.40"
Weight (Approximate): 12.80 oz
