Specifications: Supported APIs:
Windows
- DirectShow
- DirectKS
- Wave API/DirectSound/WASAPI
Linux
- V4L2
- ALSA
Supported Software
VLC
VirtualDub
OBS
xSplit
vMix
VidBlaster
Wirecast
Microsoft Media Encoder
Adobe Flash Media Encoder
Any other DirectShow/V4L2 encoding/streaming software
Input Features
Support for input video resolutions up to 2048x2160 pixels
HDMI Specific Features:
225MHz HDMI receiver
Adaptive HDMI equalizer support for cables lengths up to 30M
Support for customized EDID
Support for extraction of AVI/Audio/SPD/MS/VS/ACP/IRSC1/ISRC2/ Gamut InfoFrames
Full colorimetry support
Support for 8/10/12-bit color depths
Support for RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 color sampling
Support for up to 8-channel IEC60958/IEC61937 audio streams
Support for extraction of audio formation information & channel status data
Supp...
Interface: PCI-Express x4 Gen 2
* Some PCIe x4 Gen 2 and M.2 slots may share bandwidth with graphics card, please consult your motherboard's user manual.
Format: Record Format: MPEG 4*
* H.264 & H.265 encoder is provided by GPU; Audio codec is provided by OS
- LGD Supports 7.1 / 5.1 Ch. LPCM surround sound pass-through
- LGD does not support viewing / recording / streaming of HDCP protected signals
