Interface: Ethernet Technology:
2.5 Gigabit Ethernet
Number of Network (RJ-45) Ports:
1
PoE (RJ-45) Port:
Yes
PoE PD Port:
Yes
Part Number: NWA90AXPRO
Antenna: Antenna Form Factor:
Internal
Certifications: Certifications & Standards:
FCC Part 15C
FCC Part 15E
ETSI EN 300 328
EN 301 893
LP0002
EN 60601-1-2
FCC Part 15B
EN 301 489-1
EN 301 489-17
EN55022
EN55024
EN61000-3-2/ -3
BSMI CNS13438
EN 60950-1
IEC 60950-1
BSMI CNS14336-1
Wireless Data Rates: 802.11b: 1, 2, 5.5, and 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
802.11n data rates on 2.4 GHz and 5GHz: 6.5 to 600Mbps (only 20 MHz and MCS 0 to MCS 15)
802.11ac data rates (5 GHz): 6.5 to 1733Mbps (MCS0-MCS9)
Interface: 2 x Gigabit (10/100/1000BASE-T autosensing), Power over Ethernet (PoE)
RJ-45 console port (not functional)
USB 2.0 (not functional)
Frequency Band: Dual radio for simultaneous dual-band operation
5 GHz 802.11ax 4x4 MIMO for up to 4.8 Gbps wireless data rate, with Multi User MIMO support (Wi-Fi 6)
2.4 GHz 802.11ax 2x2 MIMO for up to 574 Mbps wireless data rate (Wi-Fi 6)
Antenna: Down-tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 3.77 dBi in 2.4GHz and 4x4 MIMO with peak antenna gain of 4.55 dBi in 5GHz (of the effective, combined pattern for both antennas in each band)
LAN Ports: Uplink 2.5 Gigabit Ethernet port, with PoE-in support (802.3at)
DC power connector (12V) Bluetooth
Low Energy (BLE) radio LED status indicators
Reset/LED control button
Kensington security slot...
Wireless Data Rates: Wireless LAN: 802.11a/b/g/n/ac/ax/be
Interface: 1 x 1/2.5/5GBase-T (PoE) - RJ-45, 1 x 1000Base-T - RJ-45
Part Number: 901-T670-US01
Standards: 2.4 GHz, 5 GHz, 6 GHz
Network Device: Maximum data rate (2.4 GHz): 689 Mbps, Maximum data rate (5 GHz): 5765 Mbps, Maximum data rate (6 GHz): 5765 Mbps
EN 50121-1, EN 50121-4, EN 60601-1-2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-5, EN 62311, IEC 61373, IEC/EN/UL 60950-1, IEC/EN/UL 62368-1, ISTA 2A, RoHS, WEEE
Security: Integrated Layer 7 firewall with mobile device policy management
Real-time WIDS / WIPS with alerting and automatic rogue AP containment with Air Marshal
Flexible guest access with device isolation
VLAN tagging (802.1q) and tunneling with IPsec VPN
PCI compliance reporting
WEP, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X
EAP-TLS, EAP-TTLS, EAP-MSCHAPv2, EAP-SIM
TKIP and AES encryption
Enterprise Mobility Management (EMM) & Mobile Device Management (MDM) integration
Cisco ISE integration for Guest access and BYOD Posturing
Frequency Band: Dual Radio for simultaneous dual-band operation
5 GHz 802.11ac 3x3 MIMO for up to 1,300 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5)
2.4 GHz 802.11n 2x2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4)
Standards: IEEE 802.11ac, 802.11n
Antenna: Integrated downtilt omni-directional antennas with maximum individual antenna gain of 3.9dBi in 2.4GHz and 5.4dBi in 5GHz
LAN Ports: (1) uplink Gigabit Ethernet port, with POE-in support (802.3af)
Frequency Band: Dual Radio for simultaneous dual-band operation
5 GHz 802.11ac 4x4 MIMO for up to 1,733 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5)
2.4 GHz 802.11n 2x2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4)
Standards: IEEE 802.11ac, 802.11n
Antenna: Integrated downtilt omni-directional antennas with maximum individual antenna gain of 3.6dBi in 2.4GHz and 6.0dBi in 5GHz.
LAN Ports: (1) uplink Gigabit Ethernet port, with POE-in support (802.3af)
Frequency Band: Dual radio for simultaneous dual-band operation
5 GHz 802.11ax 4x4 MIMO for up to 4.8 Gbps wireless data rate, with Multi User MIMO support (Wi-Fi 6)
2.4 GHz 802.11ax 2x2 MIMO for up to 574 Mbps wireless data rate (Wi-Fi 6)
Antenna: Down-tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 3.77 dBi in 2.4GHz and 4x4 MIMO with peak antenna gain of 4.55 dBi in 5GHz (of the effective, combined pattern for both antennas in each band)
LAN Ports: Uplink 2.5 Gigabit Ethernet port, with PoE-in support (802.3at)
DC power connector (12V) Bluetooth
Low Energy (BLE) radio LED status indicators
Reset/LED control button
Kensington security slot...
Wireless Data Rates: 802.11b: 1, 2, 5.5, and 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
802.11n data rates on 2.4 GHz and 5GHz: 6.5 to 600Mbps (only 20 MHz and MCS 0 to MCS 15)
802.11ac data rates (5 GHz): 6.5 to 1733Mbps (MCS0-MCS9)
Interface: 2 x Gigabit (10/100/1000BASE-T autosensing), Power over Ethernet (PoE)
RJ-45 console port (not functional)
USB 2.0 (not functional)
Wireless Data Rates: 802.11b: 1, 2, 5.5, and 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
802.11n data rates on 2.4 GHz and 5GHz: 6.5 to 600Mbps (only 20 MHz and MCS 0 to MCS 15)
802.11ac data rates (5 GHz): 6.5 to 1733Mbps (MCS0-MCS9)
Interface: 2 x Gigabit (10/100/1000BASE-T autosensing), Power over Ethernet (PoE)
RJ-45 console port (not functional)
USB 2.0 (not functional)
