Specifications: Ports: 16 RS-232 serial ports
Throughput: Up to 230 Kbps
Signal Support: TXD, RXD, RTS, CTS, DTR, DSR, DCD
Ethernet:
Physical Layer: 10/100 Base-T
Data Rate: 10/100 Mbps
Mode: Full or Half duplex
USB: 2 ports at .5A max per port
Power Input: 100-240 VAC, 50-60 Hz, 0.4A
Surge Protection: 1 kV burst (EFT) per EN61000-4-4; 2 kV surge transient per
Security: SSL, SSL/TLS, SSHv2, FIPS 197 (serial ports), SNMPv2, PPP
Dimensions: 17.00" x 6.95" x 1.62"
Weight: 5.00 lbs.
Specifications: Port
Ports: 2
Protocol: RS232
Connector: DB9 Connector - 9 Pin Male
Tx FIFO Size: 256
Rx FIFO Size: 32
Operating Distance: EIA - RS232 Standard
Cable: No Cable; Integrated Connector
Port Settings
Max Baud Rate: 1,000,000 (1 MegaBaud)
Data Bits: 5,6,7 or 8
Parity: Odd, Even, None, Mark or Space
Stop Bits: 1 or 2
Flow Control: RTS/CTS, DSR/DTR, XON/XOFF
Tx/Rx Modes: Point to Point
Dimensions: 102(l) x 104(w) x 28(h) mm, 4.02(l) x 4.09(w) x 1.10(h) inches
