Specifications: LED: Blue LED Power Indicator
Material: Plastic
Power Connector Required: 1x SATA
Fans Ports: 10
Fan Connector Supported: 3-pin / 4-pin (3-pin not supported for PWM Function)
PWM Signal Input: 4-pin PWM Connector
Weight: 90g
Color: Black
Dimensions (L x W x H): 81 x 44 x 18 mm (3.2" x 1.75" x .70")
Mobile Rack Drives Support: Multi 2.5" Drives to 5.25" Bay
Mobile Rack Interface: SATA I/II/III
Specifications: Host Interface: 7 pin SATA x 4
Drive Fit: 2.5" SATA I / II / III SSD or hard drive x 4
Drive Bay: Single 5.25" half height device bay
Transfer Rate: Up to 6 Gb / sec. (depending on hard drive speed)
Insert& Extract connection Via: Direct SATA hard drive connection
Structure: SECC
Device Power: Single 4 pin Molex power
Drive Cooling:
Dual 40mm rear cooling fan + fan power switch
Metal heat dispersion
Power Indicator: Solid Green LED
HDD Access Indicator: Flashing Amber LED
Dimension (L x W x H): 6.70" x 5.75" x 1.63"
Weight: 1.77 lbs.
Specifications: Support Drive Size: 1 x M.2 SATA SSD (2230/2242/2260/2280)
Host Interface: USB 3.2 Gen 1
Power Input: Via USB
Transfer Rate: Up to 5Gb/s (Depending on hard drive speed)
Structure / Material: ABS Plastic
Product Dimension (L x W x H): 60 x 14 x 122.5mm
Product Net Weight: 45g
Drive Activity LED Indication: SSD power: solid blue; SSD access: flashing blue
Specifications: Product Sub Category: SATA Interface
Form Factor: 3.5"
Interface: SATA / SAS Interface
Trayless Design: Trayless Design
Supported HDD Size: 2 x 2.5" HDD / SSD (Support SATA-I, II & III and each drive thickness up to 9.5mm)
Hot-Swappable: Hot-Swappable
Cage Color: Black
Material: Aluminum Cage & Front Bezel
Power Connector: 1 x SATA 15PIN
HDD Connection: 2 x SATA 7PIN
Transfer Rate: Up to 6Gb/s
RoHS Ready: RoHS Ready
Door & Lock: Metal key lock on each drive bezel
Dimension: 1.00" x 4.00" x 5.75"
Weight: 1.00 lbs.
