Specifications: Connector(s):
1 - Drive Connectors: M.2 (PCIe, SATA, M-Key, NGFF)
1 - Host Connectors: USB 3.1 USB Type C (10 pin, Gen 2, 10 Gbps)
Interface: USB 3.1 Gen 2
Bus Type: USB 3.2 Gen 2 10Gbps
Number of Drives: 1
Drive Size: 22 mm - M.2 NVMe
Compatible Drive Types: M.2 (PCIe, NVMe, M-Key, NGFF)
Drive Installation: Fixed
Compatible Drive Types: M.2 SATA (NGFF, B+M-Key)
Supported Drive Height(s):
2230
2242
2260
2280
Chipset ID: Realtek - RTL9210B
1 - LED Indicators: Power & Activity
Maximum Data Transfer Rate: 10 Gbps
Type and Rate: USB 3.2 Gen 2 - 10 Gbit/s
UASP Support: Yes
TRIM Support: Yes
4Kn Support: Yes
Type and Rate: NVMe (PCIe Gen 3)
Insertion Rating:
USB-C: 10,000 cycles
M.2: 60 Cycles
General Specifications: Fully compatible with M.2 SATA, AHCI and PCIe NVMe based drive...
Specifications: Chipset ID: JMicron - JMS580
Drive Size: 22mm - M.2 SATA
Supported Drive Height(s): 2242 / 2260 / 2280
Compatible Drive Types: M.2 (SATA, B-Key, NGFF) / M.2 SATA (NGFF, B+M-Key)
Maximum Data Transfer Rate: 6 Gbps
MTBF: 50,000 hours
TRIM Support:Yes
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s, SATA III (6 Gbps)
UASP Support: Yes
Drive Connectors: 1 - M.2 (SATA, B-Key, NGFF) Receptacle
Host Connectors: 1 - USB Type-C (24 pin) USB 3.1 (10Gbps) Male
Note:
Not compatible with M.2 NVMe or AHCI PCI-Express SSDs
Windows 7 and earlier Windows versions do not support TRIM with USB to SATA devices.
Compatibility: Windows 8.1, 10
MacOS 10.10 to 10.15, 11
Ubuntu 18.04, 20.04
Chrome OS
Android 9.0
IPadOS
Ports Spec: 1 - Internal Ports:
USB 3.1 USB Type-A (9 pin, Gen 1, 5 Gbps)
USB 3.0 A (Fast-Charge, 9 pin)
USB Type-C (24 pin) USB 3.0 (5Gbps)
Ethernet Gigabit
HDMI
VGA (14 pin, High Density D-Sub)
1 - Host Connectors:
USB Type-C (24 pin) USB 3.0 (5Gbps)
Compatibility: MacOS High Sierra (10.13)
MacOS Mojave (10.14)
MacOS Catalina (10.15)
MacOS Big Sur (11.0)
Windows 8
Windows 10
Chrome OS
IPad OS
Android
Ports Spec: 1 - External Ports:
HDMI
USB 3.1 USB Type-A (9 pin, Gen 1, 5 Gbps)
USB 3.0 A (Fast-Charge, 9 pin)
SD / MMC Slot
MicroSD
USB-C (24 pin) USB Power Delivery only
RJ-45
1 - Host Connectors:
USB Type-C (24 pin) USB 3.0 (5Gbps)
Specifications: Drive Connectors 1 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors 1 - USB 3.1 USB Type-A (9 pin; Gen 2; 10 Gbps) Male
Bus Type: USB 3.1 Gen 2
Chipset ID: ASMedia - ASM1351
Compatible Drive Types (Type and Rate): SATA
Drive Size: 2.5in
Interface: USB 3.1 Gen 2
Number of 2.5 inch bays: 1
Number of Drives: 1
Hot Swap Capability: Yes
Max Drive Capacity: Currently tested with hard drives up to 2TB at 7200 RPM
Maximum Data Transfer Rate : 10 Gbps
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s
UASP Support: Yes
Specifications: Bus Type: USB 3.1 Gen 2
Chipset ID: ASMedia - ASM1351
Compatible Drive Types (Type and Rate): SATA
Drive Size: 2.5in & 3.5in
Interface : USB 3.1 Gen 2
Number of Drives: 1
Hot Swap Capability: Yes
Max Drive Capacity: Currently tested with hard drives up to 6TB
Maximum Data Transfer Rate: 10 Gbps
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s, SATA III (6 Gbps)
UASP Support: Yes
LED Indicators: 1 - Power and Activity
Center Tip Polarity: Positive
Input Current: 0.6 A
Input Voltage: 110 ~ 240 AC
Output Current: 2.0 A
Output Voltage: 12 DC
Plug Type: M
Power Source: AC Adapter Included
