Long Term Operating Temperature: -250 °C / +150 °C
Specifications: The Thermal Grizzly Carbonaut pad is a carbon fiber thermal pad. Its special developed polymer results in its flexibility and its soft 'gap filler' properties. The carbon fiber structure ensures excellent thermal conductivity. Thermal Grizzly Carbonaut is lightweight and reusable. In addition, Thermal Grizzly Carbonaut has a very high thermal conductivity even with very little contact pressure. Thermal Grizzly Carbonaut heat transfer performance always remains constant. Note: Carbonaut is electrically conductive.
Carbonaut is available pre-assembled in many standard CPU / GPU sizes.
Size - CPU/GPU
32 x 32 - Intel Desktop CPUs (115x) e.g 6700K, 7700K, 9900K
38 x 38 - Intel 20xx HEDT CPUs and AMD Desktop CPUs. e.g. 7900X, 7980XE, 2700X, 1800X, 6950X
51 x...
Long Term Operating Temperature: -200 °C / +350 °C
Specifications: The Hydronaut thermal grease delivers optimal heat transfer capabilities for larger-scale cooling solutions like water cooling systems.
Hydronaut thermal grease consists of a silicon-free structure. The makes it very light and highly flexible and easy to apply.
Hydronaut achieves best results if used on medium- to large-scale cooling solutions. This product is ROHS-compliant for demanding users.
Specifications: Average Particle Size:
<0.36 micron <0.000014 inch (70 particles lined up in a row equal 1/1000th of an inch.)
Temperature Limits:
Peak: -150 Degrees C to >185 Degrees C
Long-Term: -150 Degrees C to 130 Degrees C
Coverage Area:
2.7-gram syringe. (Approximately 1cc)
At a layer 0.003" thick, one syringe will cover about 22 square inches.
25-gram syringe. (Approximately 9.2cc)
At a layer 0.003" thick, one syringe will cover about 200 square inches.
Specifications: Dimensions
50x50 mm or 145x145 mm(based on model)
Thickness
0.5 mm or 1.0 mm or 1.5 mm (based on model)
Thermal Conductivity
6.0 W/mK
Hardness
25 Shore 00
Specific Gravity
3.2 g/cm3
Colour
Blue
Continuous Use Temperature
-40~200 C
Volume resistance
1 X 1012 O-cm
Breakdown Voltage
12 KV/mm
Tensile strength
2.5 Kgf/cm²
Elongation
45 %
