Specifications: HDMI Resolution: Max input can support 3840x2160@30Hz / 4K Video Output Resolution: Max output can be 1920x1080@30Hz Video Input Format: 8 / 10 / 12-bit Deep Color Video Output Mode: YUV / JPEG Support Audio Format: L-PCM Support AWG26 HDMI Standard Cable: input =15 meters, AWG26 HDMI standard cable. Maximum Working Current: 0.4A / 5VDC Operating temperature range: (-10 to + 55°C ) Dimension (L x W x H): 2.52" x 1.10" x 0.51" Weight: 0.05 lb.
Package Contents: 1 x Audio Video Capture Card HDMI to USB 1 x User Manual
Specifications: Supported APIs:
Windows
- DirectShow
- DirectKS
- Wave API/DirectSound/WASAPI
Linux
- V4L2
- ALSA
Supported Software
VLC
VirtualDub
OBS
xSplit
vMix
VidBlaster
Wirecast
Microsoft Media Encoder
Adobe Flash Media Encoder
Any other DirectShow/V4L2 encoding/streaming software
Input Features
Support for input video resolutions up to 2048x2160 pixels
HDMI Specific Features:
225MHz HDMI receiver
Adaptive HDMI equalizer support for cables lengths up to 30M
Support for customized EDID
Support for extraction of AVI/Audio/SPD/MS/VS/ACP/IRSC1/ISRC2/ Gamut InfoFrames
Full colorimetry support
Support for 8/10/12-bit color depths
Support for RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 color sampling
Support for up to 8-channel IEC60958/IEC61937 audio streams
Support for extraction of audio formation information & channel status data
Supp...
Specifications: Supported APIs:
Windows
- DirectShow
- DirectKS
- Wave API/DirectSound/WASAPI
Linux
- V4L2
- ALSA
Supported Software:
VLC
VirtualDub
OBS
xSplit
vMix
VidBlaster
Wirecast
Microsoft Media Encoder
Adobe Flash Media Encoder
Any other DirectShow/V4L2 encoding/streaming software
Input Features: Support for input video resolutions up to 2048x1080 pixels
SDI Specific Features:
Integrated cable equalizer supporting cable lengths up to 230M for HD signals
Support for SD/HD/3Ga/3Gb/3Ga-DL/3Gb-DS standards
Support for 2K (2048x1080) mode
Support for RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 color sampling
Support for 10/12-bit color depth
Support for extraction of SMPTE 352 payload identifier
Support for up to 8 (mono) audio channels at 48KHz (channels 1-8 from the 16 available in the SDI spec)
Support for extraction of audio format...
