Specifications: Device Control:
Sony compatible RS422 deck control ports. Serial ports TxRx direction reversible under software control.
Supported Codecs:
AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, Apple ProRes 4444, Apple ProRes 422 HQ, DNxHR & DNxHD, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10 bit 4:4:4.
Software Included: Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux.
Internal Software Upgrade: Firmware built into software driver. Loaded at system start or via updater software.
Physical Installation: PCI Express 4...
Interface: PCI-Express x4 Gen 2
* Some PCIe x4 Gen 2 and M.2 slots may share bandwidth with graphics card, please consult your motherboard's user manual.
Format: Record Format: MPEG 4*
* H.264 & H.265 encoder is provided by GPU; Audio codec is provided by OS
- LGD Supports 7.1 / 5.1 Ch. LPCM surround sound pass-through
- LGD does not support viewing / recording / streaming of HDCP protected signals
Specifications: Max Pass-Through Resolutions:1080p60
Max Record Resolutions:1080p60
Supported Resolutions (Video input): 1080p, 1080i, 720p, 576p, 480p, 480i
Record Format: MPEG 4 (H.264+AAC) / MJPEG
Dimension (W x D x H):125 x 151 x 21.5 mm (4.92 x 5.94 x 0.84 in)
Weight:145 g (5.11 oz.)
Notes:
LGHD2 does not support viewing/recording/streaming of HDCP protected signals
Interface: PCI Express x1 Gen 2
Ports In: HDMI*, 3.5mm audio
* LGHD2 does not support viewing/recording/streaming of HDCP protected signals
