Specifications: USB-C to VGA cord connects your VGA display to the USB-C or Thunderbolt 3 port on your laptop, MacBook or Chromebook.
Transmits video signals from sources supporting USB DisplayPort Alt Mode
Delivers HD picture quality at resolutions up to 1920 x 1080 (1080p) @ 60 Hz
Supports USB 3.1 Gen 1 speeds up to 5 Gbps to ensure fast data transfers
Reversible USB-C plug connects in either direction for immediate no-fuss use
Easy installation with plug-and-play operation-no software required
Connector:
Side A - Connector 1: USB-C (MALE)
Side B - Connector 1: VGA (FEMALE)
Specifications: Chipset ID: MCT - Trigger 1+
Memory: 16MB SDRAM
USB Pass-Through: No
General Specifications: This USB video adapter uses a Trigger family chipset. If you’re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a DisplayLink or Fresco family chipset.
Supported Resolutions: Standard (1600 x 1200, 1400 x 1050, 1280 x 1024, 1280 x 960, 1152 x 864, 1024 x 768, 800 x 600) / Widescreen (1680 x 1050, 1440 x 900, 1280 x 800, 1280 x 768, 1152 x 864, 800 x 600)
Connector A: 1 x USB Type-A (4 pin) USB 2.0 Male Input
OS Compatibility: Windows 10 (32/64) / Windows 8 / 8.1 (32/64) / Windows 7(32/64) / Windows Vista (32/64) / Windows XP (32/64)
System and Cable Requirements: One available USB 2.0 port
Changer Type: USB Type-C to Type-A, VGA & Type-C Adapter
Color: White
Specifications: Connect A: USB 3.1 Type-C Male
Connect B: USB 3.0 Type-A Female / VGA (HD15) Female / Type-C Female
Compatible Devices for USB 3.1 Type-C with DP Alt Mode or Thunderbolt 3 (not a full list)
PC:
MacBook 2015 and newer/ MacBook Pro 2016 and newer/ iMac 2017 and newer/ iMac Pro 2017 and newer
MacBook Air 2018/ iPad Pro 2018 / New Mac Mini
Dell XSP 15/13
ASUS T303ua/ ZenBook 3
Lenovo YOGA900/910/920 / Lenovo Thinkpad X1 Carbon 5th
Chromebook Pixel 2
HP EliteBook Folio G1/ Spectre 13 X360
Huawei Matebook
And more...
Smartphones:
Huawei Mate 10
Samsung Galaxy S8/S8+/S9 / Samsung Galaxy Note8/9
Microsoft Lumia 950 / LG G5 / V20 / V30
And more...
Specifications: Converter Type: Format Converter
Maximum Analog Resolutions: 2048 x 1280 @ 60hz
Maximum Digital Resolutions: 1024 x 768, 1280 x 720, 1920 x 1080, 1920 x 1200, 2048 x 1280
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) Male Input
Humidity: 25% to 85% RH Non-Condensing
Operating Temperature: 5 to 35 degree C (41 to 95 degree F)
Storage Temperature: 5 to 35 degree C (41 to 95 degree F)
Specifications: Connector A: USB C (MALE)
Connector B: HD15 (FEMALE)
Chromebook Compatible: Yes
System Requirements
Windows XP, Vista, 7, 8 or 8.1 or Mac OS X 10.8.3 and later (32- and 64-bit versions)
Computer with USB-C port and at least 1.2 GHz single-core CPU and 512 MB of RAM
HDMI-enabled monitor
Supports Surface tablets running non-RT Windows 8 or 8.1
Specifications: Connect A: USB 3.1 Type-C Male
Connect B: HDMI Female / VGA Female
Compatible Devices for USB 3.1 Type-C with DP Alt Mode or Thunderbolt 3 (not a full list)
PC:
MacBook 2015 and newer/ MacBook Pro 2016 and newer/ iMac 2017 and newer/ iMac Pro 2017 and newer
MacBook Air 2018/ iPad Pro 2018 / New Mac Mini
Dell XSP 15/13
ASUS T303ua/ ZenBook 3
Lenovo YOGA900/910/920 / Lenovo Thinkpad X1 Carbon 5th
Chromebook Pixel 2
HP EliteBook Folio G1/ Spectre 13 X360
Huawei Matebook
And more...
Smartphones:
Huawei Mate 10
Samsung Galaxy S8/S8+/S9 / Samsung Galaxy Note8/9
Microsoft Lumia 950 / LG G5 / V20 / V30
And more...
Specifications: Active or Passive Adapter: Active
Adapter Style: Adapters
AV Input: USB Type-C
AV Output: HDMI, VGA
Chipset ID: ITE - IT6222
Audio Specifications: HDMI output: 5.1 surround sound
Maximum Analog Resolutions: 1920 x 1200 @ 60Hz (VGA)
Maximum Digital Resolutions: 3840 x 2160 @ 30Hz (HDMI)
Supported Resolutions:
Maximum HDMI output:3840 x 2160 @ 30Hz
Maximum VGA output: 1920 x 1200 @ 60Hz
Lower resolutions and refresh rates may also be supported
Video Revision: HDMI 2.0
Specifications: 6 inch USB-C to VGA, USB 3.0, USB-C Power Pass-Through Multiport Dock
The multiport dock from PI Manufacturing allows you to expand the ports and display connectivity options for your desktop, laptop, or other USB-C enabled device. The dock include a VGA port for outputting to a VGA display with support for resolutions up to 1920x1200 or 1080p, an USB 3.0 port for plugging in printers, external hard drives, thumb drives, and more, and a USB-C power delivery pass-through port for charging via your laptop's power adapter while the dock is in use.
Compact / Portable Size
The USB-C dock is perfect for on-the-go travel and comes with all the ports necessary for most applications.
Display Resolution
Support for resolutions up to 1920 x 12...
Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID:
VIA/VLI - VL102
VIA/VLI - VL817
Parade - PS8338B
Parade - PS176
Analogix - ANX9833
ALCOR MICRO - AU84612
Realtek - RTL8153
Fast-Charge Port(s): Yes
Industry Standards:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Audio Specifications: The HDMI port supports audio output
Compatible Networks: 10/100/1000 Mbps
Auto MDIX: Yes
Full Duplex Support: Yes
Maximum Resolutions:
1920 x 1200p @ 60Hz (VGA)
3840 x 2160p (HDMI) @ 30Hz
Lower resolutions are also supported. For example, if the max is 3840 x 2160p (4K), it also supports 2560 x 1600p and 2560 x 1440p
Maximum Data Transfer Rate : 5 Gbps (USB 3.0), 2 Gbps (Ethernet; Full-Duplex)
UASP Support: Yes
Powe...
Specifications: Audio Specifications: HDMI and mDP output - 7.1 surround sound
General Specifications: Only one video output is supported on the video adapter at a time. If multiple connections are made, only one of the outputs will function.
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: 3840 x 2160
Supported Resolutions:
HDMI and mDP output: 3840 x 2160, 2560 x 1600, 1920 x 1200, 1920 x 1080, 1280 x 720
DVI and VGA output: 1920 x 1200, 1920 x 1080, 1280 x 720
Video Revision: DisplayPort 1.2
Wide Screen Supported
Humidity: 40%-50%RH
Operating Temperature: 0°C to 70°C (32°F to 158°F)
Storage Temperature: -10°C to 80°C (14°F to 176°F)
