Frequency Band: Frequency Band:
2.40 GHz
5 GHz
6 GHz
Indoor/ Outdoor:
Indoor
Wireless Transmission Speed:
7.80 Gbit/s
MIMO Technology:
Yes
MIMO Type:
Multi User MIMO
Beamforming Technology:
Yes
Data Encryption:
Yes
Encryption Standard:
WEP
WPA
WPA2-PSK
WPA3
WPA3-ENT
WPA2
Interface: Ethernet Technology:
2.5 Gigabit Ethernet
Gigabit Ethernet
Number of Network (RJ-45) Ports:
2
PoE PD Port:
Yes
Wi-Fi Generation:
Wi-Fi 6E
Communication Protocols:
RADIUS
SNMP
Wireless Performance:
AXE7800
Part Number: WAX640S-6E
Standards: Wireless LAN Standard:
IEEE 802.11 a/b/g/n/ac/ax
Network Band:
Tri Band
Interface: One 10/100/1000/2.5GBASE-T Gigabit Ethernet (RJ-45) ports with Auto Uplink (Auto MDI-X) supporting IEEE 802.3af or 802.3at Power over Ethernet (PoE)
Interface: One 10/100/1000/2.5GBASE-T Gigabit Ethernet (RJ-45) ports with Auto Uplink (Auto MDI-X) supporting IEEE 802.3af or 802.3at Power over Ethernet (PoE)
Interface: 1 x Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)
Standards: IEEE 802.11ax/ac/n/g/b/a
Security: Captive Portal Authentication§
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Wireless Data Rates: Max bandwidths and peak data rate per band: 20/40 (2.4 GHz), 20/40/80 (5 GHz), 20/40/80/160 (6 GHz), and maximum peak data rate 3.6 Gbps
Frequency Band: 2.4 GHz and 5 GHz or 2.4 GHz and 6 GHz or 5 GHz and 6 GHz
Interface: Wired Network Interface: 1 x 2.5GbE, 4 x 1GbE
Ports:
Uplink (E0): Ethernet wired network port (RJ-45)
Downlink (E1-–E4): Ethernet wired network ports (RJ45)(E1 and E2: POE-PSE) USB 2.0 host interface (Type A connector)
Cellular radio module interface (accessible after removing the back cover) Serial console interface (proprietary, micro-B USB physical jack) Kensington security slot
