SABRENT
The Sabrent 4TB Rocket 4 PLUS NVMe 4.0 Gen4 PCIe M.2 Internal SSD Extreme Performance Solid State Drive (SB-RKT4P-4TB) delivers all the advantages of flash disk technology with PCIe Gen4.0 x4 interface.
Based on TLC NAND Flash memory, its performance speeds can reach up to 7100 MB/s (read) and 6600 MB/s (write) when using a PCIe Gen4 motherboard. Using a PCIe Gen3 Motherboard Speeds will reach up to 3400 MB/s (read) and 3000 MB/s (write). Power consumption is much lower than traditional hard drives, making it the best embedded solution for new systems.
Note: In order to take advantage of these speeds, a PCIe Gen4 motherboard is REQUIRED. Otherwise, it will be a PCIe gen 3 speed at the max of 3400MB/s.
When installing any NVMe PCIe 4.0 SSD directly onto a PCIe Gen4 Motherboard a Heatsink is required to dissipate the heat generated by the drive's extreme speed levels to avoid thermal throttling and maximize performance.
The SABRENT 4TB Rocket 4+ Nvme PCIe 4.0 M.2 2280 Internal SSD is backward compatible with PCIe 3.0. Using a Gen 3 PCIe motherboard will enable the user to reach speeds of up to 3400 MB/s (read) and 3000 MB/s (write).
- NVMe M.2 PCIe Gen4 x4 Interface.
- PCIe 4.0 Compliant / NVMe 1.3 Compliant.
- Power Management Support for APST / ASPM / L1.2.
- Supports SMART and TRIM commands.
- Supports ONFi 2.3, ONFi 3.0, ONFi 3.2 and ONFi 4.0 interface.
- Advanced Wear Leveling, Bad Block Management, Error Correction Code, and Over-Provision.
- Upgradeable Firmware.
- All SABRENT SSDs come with FREE SABRENT Acronis True Image for SABRENT Software for easy Cloning, For more information please visit our website.
| Products | ||||
|---|---|---|---|---|
| Model # | SB-RKTQ-4TB | SB-ROCKET-4TB | SB-RKTQ4-4TB | SB-RKT4P-4TB |
| Capacity: | 4 TB | 4 TB | 4 TB | 4 TB |
| Products | |||||
|---|---|---|---|---|---|
| Model # | SB-RKTQ-8TB | SB-RKT4P-4TB | SB-RKT4P-2TB | SB-RKT4P-1TB | SB-RKT4P-500 |
| Capacity: | 8 TB | 4 TB | 2 TB | 1 TB | 500 GB |
| Interface: | PCIe Gen. 3 X 4 | PCIe Gen. 4 X 4 | PCIe Gen. 4 X 4 | PCIe Gen. 4 X 4 | PCIe Gen. 4 X 4 |
| Max Sequential Read: | 3300 (MB/s) | 7100 (MB/s) | 7100 (MB/s) | 7000 (MB/s) | 7000 (MB/s) |
| Max Sequential Write: | 2900 (MB/s) | 6600 (MB/s) | 6600 (MB/s) | 5300 (MB/s) | 3500MB |
| NAND: | QLC | TLC | TLC | TLC | TLC |
| Products | ||||||
|---|---|---|---|---|---|---|
| Model # | EC-SNVE | EC-M2MC | EC-NVME | EC-WPTF | EC-T3NS | EC-T3DN |
| Capacity: | M Key & (B+M) Key | B+M Key 2242/2260 | M Key M.2 PCIE-based 2280/2260/2242/2230 | M Key M.2 SSD 2280/2260/2242/2230 | M Key M.2 SSD 2280/2260/2242/2230 | NVMe M.2 form factor compatible with sizes: 2242/2260/2280. |
| Transmission Speed: | 10 Gbps | 5 Gbps | 10 Gbps | 10 Gbps | Thunderbolt 1600 MB/s | Thunderbolt 1600 MB/s |
| Material: | Aluminum | Aluminum | Aluminum | Aluminum | Aluminum | |
| Max Capacity: | 8TB | 8TB | 8TB | 8TB | 8TB | 8TB |
| Tool Free: | Screw set with screw driver included | Screw set with screw driver included | ||||
| Cable: | Type C - Type C Cable | Micro USB B Cable | Type C - Type A Cable Type C - Type A Adapter | Type C - Type A Cable Type C - Type C | Thunderbolt 3 cable | Thunderbolt 3 cable |
| SSD INCLUDED: | -- | -- | -- | -- | -- | -- |
