Learn more about the Seagate ZP500NM3A002
Model| Brand | Seagate |
|---|
| Series | IronWolf 525 |
|---|
| Model | ZP500NM3A002 |
|---|
| Device Type | Internal Solid State Drive (SSD) |
|---|
| Used For | Consumer |
|---|
Details| Form Factor | M.2 2280 |
|---|
| Capacity | 500GB |
|---|
| Memory Components | 3D TLC |
|---|
| Interface | PCI-Express 4.0 x4, NVMe 1.3 |
|---|
Performance| Max Sequential Read | Up to 5000 MBps |
|---|
| Max Sequential Write | Up to 2500 MBps |
|---|
| 4KB Random Read | Up to 420,000 IOPS |
|---|
| 4KB Random Write | Up to 630,000 IOPS |
|---|
| Terabytes Written (TBW) | 700TB |
|---|
| MTBF | 1,800,000 hours |
|---|
Environmental| Power Consumption (Idle) | 20 mW |
|---|
| Power Consumption (Active) | 5.6W |
|---|
| Operating Temperature | 0°C ~ +70°C |
|---|
| Storage Temperature | -40°C ~ +85°C |
|---|
| Max Shock Resistance | 1500G |
|---|
Dimensions & Weight| Height | 3.58mm |
|---|
| Width | 22.15mm |
|---|
| Depth | 80.15mm |
|---|
| Weight | 8.00g |
|---|
Additional Information| First Listed on Newegg | October 13, 2025 |
|---|
