An Full HD webconferencing camera for corporate, education and telemedicine applications with 10x optical zoom , combined with premium color restoration, captures stunning live images to capture quality color video images in corporate conference rooms, classrooms, training centers and medical rooms.With advanced control algorithm can achieve accurate, smooth and quiet PTZ control, the camera can easily cover all indoor people during video conferencing, equipped with 255 preset positions, allowing it to easily and quickly reproduce clear pictures, and without any interference to the speaker or audience.To facilitate control and viewing, it can output HDMI interfaces, with the option to use RS232 or RS485 interface.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Precise positioning, smooth and quiet PTZ controlAdopt advanced servo control algorithm (optional) and precision stepper motor drive, it operates very quietly, smoothly and smoothly, and can move to the designated position precisely and quickly10x optical zoom with 55° high-quality wide-focus lens1080P Full HDHigh-quality HD CMOS sensor with effective 2 megapixels for high-quality images with high resolution up to 1920x1080 high frame rateThe new CMOS image sensor with an output frame rate of 60fps at 1080P can effectively reduce image noise in low-light conditions, while applying 2D and 3D noise reduction algorithms to greatly reduce image noise, even in ultra-low-light conditions It still keeps the picture clean and clear, and the image signal-to-noise ratio is as high as 52dB or moreremote controlUse RS232 and RS485 serial ports to control the camera
Precise positioning, smooth and quiet PTZ control True FULL HD images 10x optical zoom USB3.0 full HD multi-format video output Provide USB3.0 interface. At the same time provide HDMI interface, CVBS port, IP port and audio port. Support 1080P60/50, 1080P30/25 and other high-definition video formats. Support 1080P60/50/30/25, 720P60/50/ and other high-definition video formats. RS-232C/RS485 (optional) remote control (VISCA protocol/Pelco-D/Pelco-P) Through the RS-232 cascade interface, multiple cameras can be connected (VISCA protocol) Multiple address settings 255 position presets multifunction remote Infrared remote control signal transparent transmission function Optional camera flip function OSD English menu function Rich OSD menu, English OSD menu can be controlled by remote control
camera parameters
imaging sensor
A 1 / 2.8-inch high-quality HD CMOS sensor
Effective pixel
16:9 The 2.1 million effective pixels
Video format
1080 i60/i50 . 1080 p30/p25. 720 p60/p50
Lens zoom
10x optical zoom, 12 x digital zoom f 4.7mm 47mm
angle of view
4.7/5.2° (narrow) - -62 (wide)
minimal illumination
0.1Lux
white balance
Automatic / indoor / outdoor / manual
focus
Automatic / manual
iris diaphragm
automatic
shutter
automatic
noise-signal ratio
>50dB
HD video interface
HDMI USB3.0 IP CVBS Audio
Control signal interface
8mini DIN
Control signal format
Baud rate 9600/4800/2400bps
Power interface
HEC3800 convenienve receptacle
Support operating system
Windows XP,Vista,7,8, Mac OS X, Linux
USB protocol
UVC1.1
The USB Interface PTZ Control
Support for PTZ control
mechanical behavior
Horizontal rotation: ±170 ; Turn pitch: -30 +210
mechanical behavior
Horizontal speed: 1-100 / s; pitch speed: 1-60 / s
mechanical behavior
Preset bit speed: level: 100 / s, pitch: 60 / s
mechanical behavior
Preset bit accuracy: 0.1 degrees
mechanical behavior
Number of preset bits: 255 users can set the preset
Color
black
Power adapter
AC110V-AC220VDC12V/2A
input voltage
DC12V(DC11.5-DC12.5V)
power dissipation
15W (max.)
Storage temperature
-10 to +60
working temperature
0 to 45
size
155mmX186mmX172mm
Weight (net weight)
2.5KG(1.3KG)
service environment
indoor
Learn more about the SMTAV SDI camera
Model
Brand
SMTAV
Series
SDI camera
Model
SDI camera
Details
Bundled Camera Number
1 Camera
Camera Type
1
Network Camera
Yes
Type
PTZ Camera
Connection Type
HDMI
Color
Black
Mounting Location
no
Network
Wireless
no
ONVIF
no
Camera
Pan/Tilt
Yes
Pan/Tilt/Zoom
yes
Sensor & Detector
CMOS
HD Resolution
1080P
Lens Type
Optical Zoom Lens
Optical Zoom
Yes
Night Vision
no
Power
Power over Ethernet
No
Power
DC 12V
Working Environment
Temperature
0? to + 45?
Dimension & Weight
Dimension
155mmX186mmX172mm
Weight
2.5KG
Additional Information
Date First Available
April 22, 2022
