Learn more about the TYAN S4980G2NR
ModelBrand | TYAN |
---|
Model | S4980G2NR |
---|
Supported CPUCPU Socket Type | Quad 1207(F) |
---|
CPU Type | Four AMD Opteron (Rev.F) 8000 series |
---|
System Bus | Up to 1.0GHz Hyper-Transport link support |
---|
ChipsetsNorth Bridge | NVIDIA nForce Professional 3600 |
---|
Other Chipset | SMSC SCH5017 |
---|
MemoryNumber of DDR2 Slots | 16 x 240Pin |
---|
DDR2 Standard | DDR2 667 |
---|
Maximum Memory Supported | 64GB |
---|
Channel Supported | Dual Channel |
---|
ECC Supported | Yes |
---|
Registered | Yes |
---|
Expansion SlotsPCI Express x16 | 1 x PCI-E x16 slot (2nd slot, 2x controller) |
---|
Storage DevicesPATA | 1 x ATA 133 2 Dev. Max |
---|
SATA | 6 x SATA 3.0Gb/s |
---|
SATA RAID | 0/1/0+1/5 JBOD |
---|
Onboard VideoOnboard Video Chipset | XGI Volari Z7 |
---|
Onboard LANLAN Chipset | Marvell 88E1116 |
---|
LAN Speed | 10/100/1000Mbps |
---|
Second LAN Chipset | Marvell 88E1116 |
---|
Second LAN Speed | 10/100/1000Mbps |
---|
Max LAN Speed | 2 x 1Gbps |
---|
Rear Panel PortsPS/2 | 2 |
---|
COM | 1 |
---|
Video Ports | D-Sub |
---|
USB 1.1/2.0 | 2 x USB 2.0 |
---|
DimensionsForm Factor | Extended ATX |
---|
Dimensions (W x L) | 12.0" x 13.0" |
---|
Additional InformationDate First Available | May 10, 2019 |
---|
