Quick View
Digi 70001919 PortServer TS 4 H MEI 4-Port Device Server- Type: Device Server
- Specifications: Interfaces/Ports:
4 x RJ-45
1 x RJ-45
Data Transfer Rate:
10 Mbps Ethernet
100 Mbps Fast Ethernet
230 Kbps Serial
Management:
Telnet
SNMP
Digi Port Authority-Remote
HTTP for easy browser configuration
Security Features:
SSHv2
SSL/TLS
- Parts: 1 year limited
- Labor: 1 year limited
- Model #: 70001919

Quick View
perle 04030124 IOLAN DS1 Device Server- Type: Device Server
- Specifications: Processor: MPC852T
Motorola 66 MHz
Standard Memory:
16 MB RAM
Maximum Memory:
4 MB Flash Memory
Interfaces/Ports:
1 x DB-9
Flow Control:
Hardware Flow Control
Functions:
The IOLAN DS1 is ideal for connecting serial-based COM port, UDP or TCP socket based applications to remote devices. Perle's TruePort re-director provides fixed TTY or COM ports to server based applications enabling communication with remote devices connected to Perle device servers. You can also tunnel serial data between devices across an IP network.
Management:
Web browser, CLI-Telnet, shared console port, SNMP MIB II, read and write, Perle DeviceManager
Protocols:
TCP/IP, ARP, RARP, UDP, ICMP, BootP, DHCP, TFTP, Telnet, Reverse Telnet
Security Features:
Local database
Status Indicators:
Power/Ready Link status/Lan Speed Network Link activ...
- Model #: 04030124

Quick View
Brainboxes ES-446 1 Port RS232 PoE Ethernet to Serial Adapter- Type: Adapter
- Specifications: Serial Port
Ports: 1
Protocol: RS232
Connector: DB9 Connector - 9 Pin Male
Tx FIFO Size: 256
Rx FIFO Size: 32
Operating Distance: EIA - RS232 Standard
Cable: No Cable; Integrated Connector
Serial Port Settings
Max Baud Rate: 1,000,000 (1 MegaBaud)
Data Bits: 5, 6, 7 or 8
Parity: Odd, Even, None, Mark or Space
Stop Bits: 1 or 2
Flow Control: RTS / CTS, DSR / DTR, XON / XOFF
Tx / Rx Modes: Point to Point
Power
Power Input: Power Over Ethernet OR 5 - 30V DC input, reverse polarity protected
Power Over Ethernet: IEEE 802.3af
Power Supply 1 Description: Optional Global Power Supply - PW-800
General
Mounting Accessories 1 Description: DIN-Rail Mounting Kit - MK-048
PCB Layers: 4
Operating System Compatibility
Operating Systems:
Communicate with Device over TCP from any OS
Microsoft Windows 10
Microsoft Windows 8 32 bit & 64 bit Editi...
- Model #: ES-446
