Specifications: Dimensions: 27.10 x 46.80 x 119.75 mm (1.07" x 1.84" x 4.71")
Weight: 150 g (5.29 oz)
Enclosure: Anodized Aluminum
Processor: APQ8053 with 2 GB RAM
eMMC Memory: 32 GB
Management Interface: UniFi App; UniFi Network Interface
Networking Interface: (1) 10/100/1000 Ethernet Port
Configuration Interface: BlueTooth LE with Ubiquiti Mobile Applications, Web browser
Buttons: (1) Power; (1) Reset
LEDs: (1) Power, White/Blue
Power Method: Standard 802.3 af PoE, DC 5V 1A Powered
Supported Voltage Range: Standard 802.3 af PoE, DC 5V 1A
Max. Power Consumption: 5W (PoE/Adapter)
Operating Temperature: 0 to 35° C (32 to 104° F)
Operating Humidity: 20 to 80% Noncondensing
Certifications: CE, FCC, IC
Specifications: Connector type: SFP+ to SFP+
Cable length: 5 m / 16.4 ft
Cable jacket: PVC
Jacket OD: 3.0 mm
Wavelength: 850 nm
Supported data rates: 10 / 1 Gbps
Jacket color: Aqua
Ambient operating temperature: 0 to 70° C (32 to 158° F)
Specifications: Networking Interface:
PoE In (802.3af): 1 x Gigabit RJ45 Port
PoE Out (24V Passive): 1 x Gigabit RJ45 Port
Operating Temperature: 0 to 70 degree C (32 to 158 degree F)
Power Input: 48V, 802.3af
Max. Power Output: 24V, 0.5A
Power Method:
24V Passive PoE (Pairs 4, 5+; 7, 8 Return)
