| AC Input |
100-240Vac~ 14-9A 50-60Hz (Not for China) |
| AC Input |
200-240Vac~ 9A 50-60Hz (Only for China) |
| DC Output |
+3.3V +5V +12V -12V +5Vsb |
| Max Output Current |
20A 20A 100A 0.3A 3A |
| Max Combined Power |
120W 1200W 18.6W |
| Total Power |
1200W |
| Model |
HPT2-1200M,Gen5 |
| Rated Output Power |
1200W |
| Form Factor |
ATX |
| 80 PLUS Certification |
Platinum |
| Input Voltage |
100-240V |
| Input Current |
14-9A |
| Input Frequency |
50-60Hz |
| PFC |
Active PFC |
| Efficiency |
92% |
| Fan Type |
FDB Fan, 135mm |
| Dimensions(L x W x H) |
150 x 190 x 86 mm |
| Protection |
OCP, OVP, SCP, OPP, OTP, UVP |
Learn more about the FSP HPT2-1200M,Gen5
General| Brand | FSP Group |
|---|
| Model | HPT2-1200M,Gen5 |
|---|
Details| Type | ATX3.0 |
|---|
| Maximum Power | 1200 W |
|---|
| Fans | FDB Fan, 135mm |
|---|
| PFC | Active |
|---|
| Main Connector | 20+4Pin |
|---|
| +12V Rails | Single |
|---|
| PCI-Express Connector | 6 x 6+2-Pin |
|---|
| SATA Power Connector | 5 |
|---|
| Max PSU Length | 190 mm |
|---|
| Modular | Full Modular |
|---|
| Efficiency | = 92% |
|---|
| Energy-Efficient | 80 PLUS PLATINUM Certified |
|---|
| Protection | OCP, OVP, SCP, OPP, OTP, UVP |
|---|
| Input Voltage | 100 - 240 V |
|---|
| Input Frequency Range | 50-60Hz |
|---|
| Input Current | 14-9A |
|---|
| Connectors | 1 x 12VHPWR (12+4) PCIe / 1 x 24 pin (20+4) ATX / 5 x SATA / 6 x 8 pin (6+2) PCIe |
|---|
| Cable Spec | 1x ATX 20+4
3x 4+4 PIN
1x PCIe 12+4
6x PCIe 6+2
14x SATA
5x Molex (PERIPHERAL)
1x Floppy |
|---|
Features| Features | Quiet and durable cooling
Full Japanese electrolytic capacitors
Intelligent fan speed control circuit design
Unique product ID with changeable side stickers for DIY enthusiasts and gamers |
|---|
Dimension & Weight| Dimensions | 150mm x 190mm x 86mm |
|---|
Additional Information| First Listed on Newegg | November 08, 2022 |
|---|
