ViewHD 1 in 4 Out 1x4 Splitter Audio Extractor | HDMI 2.0 HDCP 2.2 4K@60Hz | 4K to 1080P Scaler | HDR Dolby Vision | 3.5mm Jack Optical and HDMI Audio Outputs to HDMI AVR Receiver | Model: UHD1X4SA

This ViewHD model UHD1X4SA is the most advanced multi-functional and versatile 4K@60Hz 18Gbps HDMI 2.0 HDCP 2.2 1x4 splitter on the planet. One input (connected to an HDMI source) goes to four outputs (connected to 4K and 1080P TVs and/or 4K or 1080P HDMI receivers. Does not strip HDCP, HDCP compliant. [I/O] one HDMI input, four HDMI outputs, one optical audio output, one 3.5 mm analog audio output. Does not support CEC, does not bypass HDCP. [4K to 1080P scaler] HDMI outputs 2, 3, and 4 have a 4K to 1080P scaler for users to enjoy 4K video on a 4K TV and 1080P video on a 1080P TV at the same time, offering excellent compatibility.

[The most advanced HDMI 1x4 splitter] supports
HDMI 2.0 b 18Gbps 4:4: 4 HDCP 2.2 HDR Dolby Vision; audio extraction supports optical receivers, 1080P and 4K HDMI receivers, and 3.5 mm stereo analog headphone output. [A powerful HDMI audio extractor] The UHD1X4SA is also an advanced HDMI audio extractor with three audio outputs: HDMI output 2, optical digital audio outputs, and stereo 3.5 mm analog output for headphones. HDMI audio output supports all HDMI V 2.0 audio formats. Optical audio output supports all audio formats up to DD/DTS 5.1C h and DD+. The 3.5 mm audio output supports incoming HDMI stereo audio format. When used as an audio extractor, it can support both older 1080P generation and current 4K HDMI receivers. [Built-in HDCP 2.2 to HDCP 1.4 converter] HDMI output 4 port is HDCP 1.4 when the HDMI input signal is HDCP 2.2. No change to the AV signal formats to support older generation of 4K@60Hz HDCP 1.4 displays. [8 custom pre-programmed settings] to enable various audio and video applications, versatile and multi-functional, supporting HDMI AVR receivers
