Specifications: Drives Supported 2.5" HDD and SSD
CONNECTIONS:
Side A - Connector 1: MICRO-USB B (FEMALE)
Side B - Connector 1: 22 PIN SATA + POWER (FEMALE)
Connector Plating: Nickel
Contact Plating: Nickel
USB Specification: USB 3.1 Gen 1 (up to 5 Gbps)
Certifications: Tested to CE, FCC, ROHS
Operating Temperature Range: 50 to 122 degree F (10 to 50 degree C)
Relative Humidity: 10% to 80%
Dimensions: Height:3.4" x Width:6.7" x Depth:11.4"
Specifications: Chipset ID: VL812+ASM1053E
Color: Black
Compatible Drive Types (Type and Rate): SATA
Drive Connectors: SATA Data & Power Combo (7+15 pin) Receptacle
Drive Installation: Removable
Drive Size: 2.5in & 3.5in
Enclosure Type: Plastic
Fan(s): Yes
Fans: 40 mm
Host Connectors: USB 3.0 B (9 pin ; SuperSpeed) Female
Humidity: 20%RH ~ 80%RH
Included in Package: Instruction manual
Universal power adapter (NA/EU/UK/AUS)
USB 3.0 4-Bay 2.5/3.5" SATA SSD/HDD Dock
USB 3.0 Cable
Input Current: 2.5A
Input Voltage: 100 ~ 240 AC
Insertion Rating: 15,000 Cycles
Interface: USB 3.0
LED Indicators: Drive power/activity LED
Max Drive Capacity: Currently tested with up to 4TB 7200 RPM 3.5" hard drives per bay (8TB total) and 2TB 5900 RPM 2.5" hard drives (2TB total)
Number of Drives: 4
OS Co...
Specifications: Interface: USB 3.0 & eSATA
Number of Drives: 2
Drive Size: 2.5in & 3.5in
Drive Type: SATA
Drive Installation: Removable
Chipset ID: JMicron - JMS562
Drive Connectors: 2 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors:
1 - eSATA (7 pin; Data) Female
1 - USB 3.0 B (9 pin; SuperSpeed) Female
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Type and Rate: SATA III (6 Gbps)
Max Drive Capacity: Currently tested with up to 4TB 7200 RPM 3.5" hard drives per bay (8TB total) and 2TB 5900 RPM 2.5" hard drives (2TB total)
Insertion Rating: 15,000 Cycles
Specifications: Creates portable external storage for dual M.2 SATA drives via the USB-C or Thunderbolt 3 port on your tablet, MacBook or Chromebook.
Connects dual 2230, 2242, 2260 and 2280 M.2 SATA SSD drives to your computer
Supports 2.5 in. SATA III (6 Gbps), II (3 Gbps) and I (1.5 Gbps) drives up to 2 TB
Supports USB 3.1 Gen 2 speeds up to 10 Gbps to ensure lightning-fast data transfers
Works up to 70% faster when connected to UASP host controller
Vented aluminum housing keeps drive cool to prevent data corruption
